User manual
Properties of products
Product performance measurement error: <=±0.3°C.
Fast: measuring time less than 1 second.
Easy to use: one-key measurement, easy to operate.
Non-contact: forehead measurement, no contact with human skin, avoid cross infection.
Overtemperature tip: set the overtemperature tip temperature freely. Usage: 100,000 keys.
Large screen display: large screen LCD backlight display, clear reading at night.
Storage data: 5 sets of measurement data are stored for easy analysis and comparison.
Settings modification: Settings parameters can be modified.
special storage conditions and the method
Products must be kept clean and in a dry place.
Do not place the product where there is an electric shock.
Do not store products in extreme temperatures above 50°C or below 0°C with humidity above 85%.
Technical index
Normal working environment conditions | 16°C ~ 35°C; relative humidity: < 85%; atmospheric pressure: 70kpa - 106kpa |
power supply voltage | DC 3V (2 No.7 alkaline batteries) |
Product size | 149mmx77mmx43mm (length x width x height) |
Host weight | 172g (excluding electric pool) |
Measurement range | body temperature mode |
accuracy | ± 0.2°C in the range of 35°C – 42°C, ± 0.3°C out of the range of 35°C – 42°C |
power dissipation | < 450mw |
measuring distance | 3cm-5cm |
automatic shutdown | 15s |
product characteristics
1. Shock-proof type: internal power equipment.
2. according to the degree of shock prevention: BF type application part
3. according to the degree of protection against harmful liquid intake: common equipment.
4. According to the safety level of flammable anesthetic gas mixed with air or mixed with oxygen or nitrous oxide: equipment that cannot be used in the presence of flammable anesthetic gas.
5. operating mode: continuous running mode.
6. The thermometer does not have the application part of protection against defibrillation discharge effect.
7. The thermometer has no signal input and signal outlet.
8. Rated voltage of the equipment: DC 3V.
9. Non-permanent installation of equipment.
10. Electromagnetic compatibility GB 4824 classification; Group Ⅰ , Class B equipment.
Delivery: Normally goods will be shipped by express, delivery time need about 7-10 working days.
FAQ
1. Your thermometer has CE certificate?
CE, FDA certificates.
2. How many pieces in one carton?
50 pcs per carton, carton size: 52*27*39 cm.
3. Can i order 10 pcs firstly to test the quality?
Yes, 10 pcs is ok, you can order more if you were satisfied to the quality.
If you were interested, please feel free to contact us for more details.
