WTTC Copper Wind Turbine Tray Cable 4X16 AWG SR -40C FT4
WTTC Copper Wind Turbine Tray Cable 4X16 AWG SR -40C FT4
Specifications
Brand Name :
TK
Model Number :
THHN-PVC TRAY cable
Certification :
CE/ISO
Place of Origin :
ANHUI,CHINA
MOQ :
500 Meter
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
100000m / Month
Delivery Time :
To be negotiated
Packaging Details :
Roll/ Wooden or steel Drum
Type :
Wind Turbine
Insulation :
PVC
Color :
Black Blue Orange Yellow Brown Red Stripe
Conductor Material :
Copper
Rated Voltage :
0.6/1kV
Sheath :
Sunlight-Resistant Polyvinyl Chloride (PVC)
Description

4X16AWG WTTC Copper Wind Turbine Tray Cable SR And -40C FT4

Wind Turbine Tray Cable (WTTC)

Cable designed to withstand the rigors of extreme conditions encountered in wind turbine applications. Designed utilizing high performance jacket material that combines exceptional oil resistance with outstanding cold temperature properties.

Applications

UL-WTTC cable applications include control and instrumentation functions in,

Pitch & Yaw drive control

- Interconnection of gearbox, blades and tower

- Brake control

- Heating and cooling systems

- Pumps & Gearbox

- Blade pitch control

- Monitoring systems

Characteristics

- Conductor : 18 to 2 AWG

- Voltage : 1000 VRMS (Max), 600 VRMS (Operating)

- Rated temperature : 90℃

- Cold Bend : -40℃, Cold Impact : -25℃

- Flammability test : FT4, IEEE 1202/383

- Torsion test : 10,000 cycles

- Oil resistance : Oil Res I & II

- Reference standard : UL Type WTTC UL 2277, c(UL) 600 V CIC

High performance WTTC cable design provides the requirements and approvals needed to assure maximum system reliability.

- 1000V UL2277 type WTTC

- 600V 1277 Type TC-ER

- -50C Cold bend, -40 Cold Impact

- Oil Res I and II

- 90C Wet and Dry; XHHW, XHHW-2

- Shielding options available

- FT4 Flame Rating
