Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Multifunctional ICU Ventilator Machine , 90L/min Ventilator Oxygen Machine
Specifications
Brand Name :
Micommon
Model Number :
30H
Certification :
CE / ISO13485
Place of Origin :
Hunan,China
MOQ :
1
Price :
To Be Negotiated
Payment Terms :
T/T, D/P, D/A, L/C
Supply Ability :
2000 Piece/Pieces per Month
Delivery Time :
15days
Ventilation mode :
S/T, CPAP, S, T, PC, VAT
Certification: :
CE ISO
IPAP: :
4-30cm H2O
Max leak compensation :
90L/min
Screen size :
5.7 inch color screen
E-Trigger setting :
Auto, 1~3 level
Description

CE ISO Certificate ICU Ventilator Machine S/T, CPAP, S, T, PC, VAT Multifunctional Ventilator

Features


Higher treatment pressure, more leak compensation.
In case of high inhalation pressure support (40cm H20) orlarge air leakage
Inhalation time function:

the minimum spontaneousinhalation time (Timin) prevents premature reversing toexhalation to ensure ventilation time
AST-Premium automatic synchronizationtechnology , excellent man-machine synchronization.
The VAT can provide tidal volume similar to volume contramode, and also has the safety of pressure control mode.
Accurate oxygen concentration control, more efficient to improve Pa02.

The oxvgen concentration isaccurate and constant, the effect of improving bloodoxygen saturation is better.

Inhalation time function.

the minimum spontaneousinhalation time (Timin) prevents premature reversing toexhalation to ensure ventilation time

Complete parameters setting.
8 hours back-up battery.

Application


* Chronic Obstructive Pulmonary Disease

* Acute Cardiac Edema
* Other ventilation problems
* Acute Exacerbation of Chronic Obstructive Pulmonary Disease
* Moderate Acute Respiratory Distress Syndrome

Specifications

Parameter ST-30H ST-30K
Ventilation mode S/T, CPAP, S, T, PC, VAT S/T, CPAP, S, T,PC, VAT, HFNC
Oxygen concentration 21%-100%, (increment by 1%)
Screen size 5.7 inch color screen
Waveform display Pressure/flow
IPAP 4-30cm H2O 4-40cm H2O
EPAR 4-25cm H2O
CPAP 4-20cm H2O
Target tidal volume 20-2500mL
Backup BPM 1-60BPM
Backup time 0.2 -4.0 S
Rise time 1-6 level
Ramp time 0-60min (increment by 1 min)
Ramp pressure CPAP mode: 4-20cm H20 Other mode: 4-25cm H20
Pressure relief 1-3 level
Spontaneous Timin 0.2-4.0 S
Spontaneous Timax 0.2-4.0 S
I-Trigger setting Auto, 1-3 level
E-Trigger setting Auto, 1-3 level
Trigger lock Off, 0.3-1.5S
Flow of HFNC mode N/A 10-70L/min
Max flov 210L/min 300L/min
Max leak compensation 90L/min 120L/min
Method of pressure measure The pressure testing tube is on mask side
Alarms Apnea | Disconnection | Low minute volumel Low tidal volume | Power off | Over high pressure | Oxygen unavailable | Excessive oxygen pressure supply | Low oxygen pressure supply | Pressure tube off | Turbine dysfunction|Oxygen sensor failure | Air flow sensor failure | Low pressure | Low battery | Battery depleted
Apnea alarm range setting 0s, 10S, 20S, 30S
Disconnection alarm range setting 0S, 15S, 60S
Real-time monitoring data Preset oxygen concentration | Oxygen source pressure |
Pressure | Ventilation per min Respiratory rate |
Current leakage | Current volume | Trigger method
Other setting Screen lock | Display brightness | Flow|Pressure | Waveform Screen lock |Display brightness | Flow|Pressure | Waveform | Event summary
Backup battery 8 hours

Humidifier parameters

　 ST-30H ST-30K
Heating range 40-70.
Adjustment 1-9 level
