Specifications
Brand Name :
RAINBOW
Model Number :
ECG-8801
Certification :
ISO13485, FSC
Place of Origin :
Hunan, China
MOQ :
1 unit
Price :
US $180-238/unit
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30000units/year
Delivery Time :
Within 3 days
Packaging Details :
Anti-collision film+ Carton box 34.5*18.5*39.5cm GW: 3.3kg
Product Name :
ECG machine
Warranty :
1 Year
After-sale Service :
Online technical support
Shelf Life :
2 years
OEM :
Available
Optional :
Printer
Net Weight :
1.4kg
Inventory :
yes
Description

Automatic Measurement Personal Single Channel ECG Machine ISO Certificated Electrocardiogram ECG-8801

Function Features of ECG Machine

Brand: Rainbow
Size: 3.5 inch
Model: ECG-8801
manufacturer: Hunan Rainbow Technology Co., Ltd

1. Power supply:AC/DC,rechargeable lithium battery inside.

2. Digital single channel automatic measurement, analysis and diagnosis with report printing

3. According to the working mode class, this device belongs to continuous operation equipment.

4. Multiple operation modes: manual, automatic, rhythm, physical examination

5. Net weight only 1.4kg,exquisite and easy to carry

6. The device can record exact single ECG waveform and remark.

7. The keyboard's control is whole touch type,it's convenient to operate.

Automatic Measurement Personal Digital Single Channel ECG Machine ISO Certificated Electrocardiogram

Standard configuration:

ECG8201 Electrocardiograph mainframe

ECG suction bulb – one pair

12-channel ECG lead

AC adaptor

Grounding wire

Body/limb clamp – one set

Power line

Thermal print paper- two rolls

Print paper scroll

Operation manual

Parameters of ECG Machine

Operation mode:Manual/Auto/storage

Standard 12 leads:real-time ECG waveforms

Measure mode:Simultaneously acquisition of 12 lead,

Measure frequency:12Bit/1000Hz(1ms)

AC filter:50Hz/60Hz

EMG filter:25Hz/45Hz

Drift filter:Auto adaption

CMRR:≥95dB

Input circuit:Floating with defibrillation protection

Frequent response:0.05-160Hz(-3db)

Sensitivity:Auto/2.5/5/10/20/40(mm/mv)

Printing:High resolution thermal printer

Communication interface:Standard USB/RS232

Safety standard:IEC I CF(GB9706.1-2007)

Keypad panel:can input clinic information such as patient names

Display:320*240 Graphical LCD

Internal power supply:built-in rechargeable li-ion battery for 8-hour battery life

External power supply:AC 75V-265V Auto adjustment for wide input range

Automatic Measurement Personal Digital Single Channel ECG Machine ISO Certificated Electrocardiogram

Automatic Measurement Personal Digital Single Channel ECG Machine ISO Certificated Electrocardiogram

FAQ

What is your MOQ?

1 unit

What is your lead time?

Within 3 days after receiving the payment

What is the payment terms?

TT(Bank Transfer), Paypal, Western Union, Moneygram, XTransfer.

What is the warranty period?

2 years warranty period

Lifetime online technical support

Do you offer OEM service?

Yes, we do
