ODM EMC Shielding Self Locking Connector 4 Pin In Straight Plug

4 Pin EMC Shielding Circular Self Locking Connector In Straight Plug

Product description

B Series Connectors
Low voltage push-pull connectors for data, signal, electrical and power use!
KNX connectors are used in medical devices, electronic instrument,and other places which need high density,

high reliability, quick mating connectors.
These high precision connectors with complete EMC shielding, shock resistance,vibration resitance,

and corrosion resistance.

Main features:
- Security of the push-pull self-latching system;
- Multipole types 2 to 26 contacts;
- Solder or print contacts(straight or elbow);
- High packing density for space savings;
- Multiple key options to avoid cross mating of similar connectors;
- Keying system for connector alignment;
- 360°screening for full EMC shielding;
- Pull-away plugs with lanyards available.

Technical parameter

Series Cable outer diameter range(mm) Pin Number

INGRESS

PROTE

CTION

 Temperature range
cable clamp cable clamp with bend relief
Min Max Min Max
00 1.1 3.4 1.1 3.4 2,3,4pin
0B 1.5 5.5 1.5 5.0 2,3,4,5,6,7,9 pin IP50 -55°C~250°C
1B 2.2 7.5 2.2 7.0 2, 3, 4, 5, 6, 7,8,10,14,16pin
2B 1.5 9.7 1.5 9.0 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18,19pin
3B 4.1 11.7 4.1 11.0 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18, 20,22,24,26,30 pin
0K 1.0 5.0 1.0 5.0 2,3,4,5,6,7,9 pin IP66-IP68 -55°C~200°C
1K 1.3 8.5 1.3 8.5 2, 3, 4, 5, 6, 7,8,10,14,16pin
2K 1.3 10.5 1.3 10.5 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18,19pin
3K 2.6 15.0 2.6 15.0 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18, 20,22,24,26,30 pin

ODM EMC Shielding Self Locking Connector 4 Pin In Straight Plug

Mechanical Details

Mechanical Details
Shell Style Straight plug, with cable collet
Key 1 key(alpha=0°；plug: male contacts,
receptacle:female contacts)
Housing material Brass Cr plated
Housing color Grey-White
Cable OD max Φ5.0mm
Jacket Grey, black
Endurance 5000 mating cycles
Operation temp.(min) -20℃
Operation temp.(max) 120℃
Humidity(max) <=95%(at 60℃/140F)

ODM EMC Shielding Self Locking Connector 4 Pin In Straight Plug

ODM EMC Shielding Self Locking Connector 4 Pin In Straight Plug

Application

1. Medical Equipment such as patient monitors and other medical device.

2. Electric vehicles.

3. Measurement devices .

4. Industrial electronic products.

5. Military products.

KNX Service and Warranty

1. Low MOQ: It can meet your business very well.
2. Good services: We treat you as our friends.
3. With a wide range of products( metal conenctor and plastic connectors and cable assemblies): can better meet your requirments .
4. Cheap price: The products are directly from our factory. So it saves a lot secondary cost.
5. OEM accepted: Please send us your design and other important information. OEM are always welcome.
