Hospital Commercial Air Handling Unit / Air Cooled Condensation Unit Low Noise Level
Hospital Commercial Air Handling Unit / Air Cooled Condensation Unit Low Noise Level
Specifications
Brand Name :
Kingbell
Model Number :
KBHM0.0H-B1
Place of Origin :
China,Shanghai
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 sets per month
Delivery Time :
30 work days
Packaging Details :
Inner standard wrapping film , outer wooden box.
Name :
Fresh air handler unit
Fan :
Centrifugal fan
After-sales service provided :
Engineers available to service machinery overseas
Type :
Air Handling Unit
Application :
Hospital
Warranty :
5 Year
Description

Hospital Commercial Air Handling Unit / Air Cooled Condensation Unit Low Noise Level

Feature

  • More beautiful surface, optional skin-color(grey or white).
  • Accessibility of entirely top-view connection of duct, pipe, and wiring. Accessibilty of entirely front-view installation work and maintenance work.
  • All devices are built in a unitary construction, including air treatment device, humidifier, and all of control device, facilitate to test and commissioning in factory.
  • EBM low noise EC fan, optimum smooth airstream design, to guarantee the unit low noise performance.
  • optimum compacted configuration, to ensure the unit directly install at service corridor, without exclusive space.

Specifications

Model Rated Air Volume Fresh Air Volume External Pressure Cooling Capacity Power Size
KBHM3.0H-B1 3000CMH 800CMH 550Pa 6kw 2.2kw/h 2030L*750D*1980H(mm)
KBHM5.0H-B1 5000CMH 1600CMH 550Pa 12kw 3kw/h 2320L*750D*1980H(mm)
KBHM10.H-B1 10000CMH 3000CMH 600Pa 12kw 5.5kw/h 2320L*750D*3000H(mm)

  1. The external residual pressure, cooling capacity and motor power in the parameter table are for reference only, and can be specifically calculated according to the actual needs of specific projects;
  2. The above unit is a standard horizontal unit, which can adjust the external dimensions of the unit according to actual needs;
  3. If you have any special requirements for the unit's external dimensions, please consult our technical department.

Hospital Commercial Air Handling Unit / Air Cooled Condensation Unit Low Noise Level
