Product Description

Technical parameters of Stimulation Apparatus:

1. Voltage:220V±22V, Frequency 50Hz±1Hz
2. Input power: 80VA
3. 1 channel of magnetic therapy output 1 channel of Electrical stimulation of the fastigial nucleus outputs, 2channel of electrical stimulation for limbs.
4. Magnetic therapy parameter:
Magnetic therapy Frequency:5Hz, 10Hz, 20Hz, 30Hz, 40Hz, 50Hz
There is no fixed frequency mode, any frequency can be choosen. Continuosly, I will take 10s±1s to change the frequency automatically. The cycling period of the 6 kinds of frequency: 60s±5s
Magnetic induction, strong :3mT-13mT weak:13mT-25mT
Magnetic therapy time :20min and 30 min
5. electrical stimulation for fastigial nucleus:
Output waveform: continuos wave, density wave, light beat wave, Massage wave E1, Massage E2, Massage E3.

The parameter for continuos wave, density wave, light beat wave:

a) Pulse period range: 0.01s~2.0s(adjustable), Error: ±10%;
b)density wave Frequency: Spacing wave frequency=4.1.
Massage wave E1 parameters:
a)Triangular wave, period: 20ms~240ms(adjustable)
b) Modulation: 100%, Error: ±15%.
Massage wave E2 parameters:
a) Sawtooth wave, period: 20ms~240ms(adjustable)
b) Modulation: 100%, Error: ±15%.
Massage wave E3 is composed of continuos wave, light beat wave and density and spacing wave.
Output pulse intensity:0~24Vpp±10%, Adjustment step: 0-99(adjustable)
The fastigial nucleus treatment time 20min

6. the electrial stimulation for the limbs parameter:
Frequency range: 2kHz~6kHz
The modulating frequency range: 0~15Hz
Modulation waveform: sine wave, square wave, triangular wave, sharp wave, exponential wave, sawtooth wave, continuous wave
Modulation mode: Continuous, interrupted, intermittence, variable frequency and alternation modulation.
35 Medium frequency treatment priscriptions
Output Current0-100mA, adjustment:0-99
The temperature range of electrode plate: 39ºC~55ºC
the electrical stimulation for the limbs time: 20min.
