Features of the high frequency electric knife:

- Maximum output power: 350W

- Eight output modes: (1) pure cut, (2) mixed cut 1, (3) mixed cut 2, (4) mixed cut 3, (5) electrocoagulation 1, (6) electrocoagulation 2, (7) electrocoagulation 3, (8) Bipolar condensate;

- Electric cut mode: pure cut 100% cut, mixed cut 1 70 % cut, 30% coagulation; mixed cut 2 50 % cut, 50% coagulation; mixed cut 3 70 % cut, 30% coagulation;

- Pure cut: Maximum output power 350W, enabling easy surgery on any tissues and structures;

- Mixed cut: Applicable for any tissue, good coagulation effect when conducting cutting;

- Electrocoagulation 1: Applicable for general open surgery and fine surgical point coagulation, featuring deep tissue coagulation layer and excellent coagulation effect;

- Electrocoagulation 2: Applicable for general open surgery and fine surgical surface coagulation;

- Electrocoagulation 3: Applicable for general open surgery and deep tissue jet coagulation surgery, featuring strong jet coagulation effect;

- Bipolar coagulation: When the tissues achieve the effect of coagulation, the output power will begin to reduce slowly to achieve good coagulation effect;

- Panel operation: Overall microcomputer automatic control, three-zone (LED) digital display, key function/power, switch/ settings, waterproof panel design;

- Automatic adjustment: Automatically fine adjust power in a certain range to ensure increasing impedance and no power decay in liquid and gasified tissues, the consistency of the cutting effect;

- Automatic recognition: Neutral unipolar/bipolar plate automatic recognition, when using the dual-circuit plates and the contact area less than 60%, it should automatically stop the power output and send sound-light alarm until the contact area returns to normal, which could effectively avoid burning patients by plates.

- Application range: Used in arthroscopic, cystoscopy, endoscopic, hysteroscopy, anorectal, general surgery, etc

Technical parameters of the high frequency electric knife:

Standard configuration sheet
