Basic Characteristics |
Reaction temperature 37.0℃ |
Control accuracy of temperature ±1.0℃ |
Test items At most 8 items can be simultaneously tested. |
Test methods Clotting assay, chromogenic substrate assay, and immunoturbidimetric assay |
Test speed PT single-item test: 100 samples/ hour |
STAT priority function |
Reagent System |
Reagent chamber, reagent position: |
With refrigerated reagent chamber, 20 refrigerated reagent positions |
Normal-temperature reagent rack, 3 normal-temperature reagent positions |
Reagent volume 20μL~175μL |
Specifications of reagent bottle 5mL, 15mL, and 50mL |
Storage temperature of reagent Refrigerated reagent ≤16.0℃ |
Automatically calculate the remaining volume and test numbers |
Automatic barcode scaning to recognize the reagent information |
Reagent liquid level sensor Integrated with probe |
Data System |
Port: Network port |
Computer configuration: Optional computer and printer |
Connection with LIS/HIS system: It is supported |
Analysis System |
Incubation and test positions: Totally 16, 8 incubation positions and 8 test positions |
Volume of cuvette: 600 μL |
Optical system: Light-emitting diode, photodiode |
Abnormal sample can be diluted and re-run automatically |
On-board adding reagents,samples and cuvettes,work effectively |
Reagent probe heating function. |
Non-contact mixing method |
QC: Real-time QC, daily QC and inter-day QC with multi-concentration method |
Complete Machine System |
Weight: 75kg |
Power consumption: 450VA |
Outline dimensions: 660mm×475mm×554mm(L×W×H) |
