Full digital B mode ultrasonic diagnostic instruments KX5100 VET USE veterinary ultrasound
Full digital B mode ultrasonic diagnostic instruments KX5100 VET USE veterinary ultrasound
Features: 1. Hand-held, 1.5kg ,smart and light. 2. 5.7" high resolution color LCD, image clear and exquisite. 3. Menu operation. 4. USB port can directly save image to U flash disk. 5. Tow pcs Li- battery work about 5 hours. 6. you can hang it with belt around your neck, so that your hands free. 7. New gridding calculate function, let doctor simply calculate the measure result by eye, save time, convenient. 8. Automatically calculate the Back-fat and Lean percentage; 9. OB function; 10. Display Back-fat ruler, easy to visualize the Back-fat thickness; 11. Pregnancy result show in English, easy to read; 12. Export EXCEL table, convenient to manage the pregnancy data; Specifications: |
Monitor | 5.7’’ high resolution color LCD |
Language: | Chinese/English switch |
Body Mark: | 1.General 2. Bovine. 3. Canine. 4. Equine. 5. Feline. 6. Cardiac. 7. Swine, etc 7 kinds, total 27 body marks with probe position. |
Display Mode: | B, 2B, 4B, B/M, M |
Gain: | 0~127dB |
Dynamic: | 27~90dB |
Gray: | 256 |
Frame frequency: | 30 frames/ second |
Image Storage: | 256 frames permanent image storage |
Cine- Loop: | 256 frames |
Dual power supply. Power: | AC110/230 -15%~+10% 1.2-0.6A |
Frequency: | 60/50Hz±1Hz |
Battery: | Two pieces large-capacity lithium Battery( 2400MAh) |
Net weight: | 1.5kg |
Main unit size: | 326x162x45mm |
