6 Nozzles Bleach Disinfectant Strong Acid Etc Corrosive Liquid Filling Machine

Applying:

This machine is especially for filling bleach toilet cleaner disinfectant etc strong acid corrosive liquid
The machine is controlled by the PLC programmable controlling system and touching screen automation, it has the merits of accurate measurement, advanced structure, non-dropping pouring, simple operation etc. The international brand is used in the electrical and pneumatic elements, ensuring good steadiness. The whole machine is made of PP materials, using PVC valve and titanium nozzles, especially for super corrosion liquid.

Features:

Good price good quality

Count testing - real-time count, reflecting on the work output directly.

Operation interface - colorful screen interface, human-machine interface is simple, safe and reliable
Control system - with Mitsubishi PLC control system, filling dose of random tuning
Electrical components - using internationally renowned brands to ensure the equipment is reliable and of high accuracy.Mechanical components - the main parts is made of high quality PP frame, contact part is made of non-toxic corrosion silica gel, titanium nozzles, PVC valve.
Filling system:Adopt the servo motor to control the feeding nozzles up and down,make sure the liquid will not spill out of the bottle.

Filling Detection - No bottle, or when bottle filling number is not enough, no filling.

Parameters:

♦ Number filling heads: 6 pcs filling heads
♦ Filling capacity: 700-5000ml can be customized
♦ Filling way: Gravity flow
♦ measurement method: microcomputer time
♦ driven method: servo motor
♦ Application bottlenecks: Customer provided bottles
♦ Filling Error: ≤±1 %
♦ Production speed: about 1000B / hour (750 filling volume)
♦ Air pressure: 0.5-0.7 M Pa

♦ Power supply: 220V/50 Hz
♦ Weight: 550kg

♦ Total Power: 1.2 KW

♦ Dimension: 2000×900×2500 mm

Competitive advantage:

1. We have seven technicians who gets passport ready to travel all over world to offer service to you.
2. We have 24hours hot line for Technical Support.
3. We get 18hours internet line for technical support.
4. Video camera in workshop to help you adjust and solve machine problem in working situation.
5. We have Technical Support in below Country:
USA (Distributor ),Italy distributor,Britishi(Distributor),India(Distributor)
