Air to water, Swimming pool heat pump,use the titanium heat exchanger,high COP,CE,GMC,ISO,UKAS, certificated
Air to water, Swimming pool heat pump,use the titanium heat exchanger,high COP,CE,GMC,ISO,UKAS, certificated
Specifications
COP :
=4.2
Use :
House pool, Commercial swimming pool,Sauna,House
Place of Origin :
Guangdong
FOB Price :
US $ 100-2,000/ PieceGet Latest Price
Housing Material :
Spray coating or stainless steel
Performance :
High efficiency
Installation :
Freestanding
Type :
Air Source Heat Pump
Storage / Tankless :
Circulation untill 35 degree
Brand Name :
E-backs
Model Number :
MDY100D
Compressor :
Danfoss,Panasonic,Copeland
Fan :
Inter scroll anial flow fan
Exchanger :
Titanium heat exchanger
Throttle :
Electric expansion valve
Advantage :
Low noise,safety,easy installation
Category :
Heat Pump Water Heaters
Payment Terms :
L/C,D/A,T/T,Western Union
MOQ :
5pcs
Supply Ability :
2000 Piece/Pieces per Month
Packaging Details :
Plywooden case with water-proof polyester film inside.
Delivery Time :
10-20 days upon receipt of the payment.
Description

Swimming pool heat pump
1.10 year's manufacturer
2.provide OEM service
3.CE certificate
4.High COP, EER
Swimming pool heat pump-42 kw,use the titanium heat exchanger,cop can reach 4.8
1.ISO, CCC and CE approval.
2.High COP, EER, 75%Energy-Saving
3.15 technology patents.
4.Intelligent main controller:cael controller Intelligerant
5.Controller:Lattle LCD
6.heating and cooling
7.Max temp can reach 55 degree
-
swimming pool heat pump 42kw
1. Compressor: copeland scroll compressor,high efficiency,low noise,long lifetime.
2. Evaporator: internal thread copper and hydrophilic aluminium foil type heat exchanger
3. Condenser: titanium material,anticorrosive,special for swimming pool water.
4. Expansion valve: electronic expansion valve adjusting refrigerant flow automatically.
5. Housing: galvanized sheet steel,good looking and anticorrosive.
6. Defrost: adopt PID defrost technology,automatically deforst.
7. Controller: set and check all paramters,protected by itself if there is something wrong with the heat pump.
8. Display panel:show working state of heat pump, and if there is something wrong, it can show the error code.
9. Compressors start one by one, so that can reduce the start current of the heat pump
10.Refrigerant: R417A/R407C/R404A,
-

-

-

2.Trade term:

Swimming pool heat pump 1

1> Packing: Standard Export Packing (Plywooden case)

2> Pay term: 30% T/T Of Total value as deposit to start the produce, And 70% the balance before shipping

3> Delivery time: within 15 days after receive the deposit

4> Effective date: The price validity is 1 month

5> Warranty: 14 months Since the delivery day

6> Discount will be offered base on one container

7> MOQ=3

-

-

Swimming pool heat pump 14 kw of specification

MODEL Unit MDY100D
Rated heating capacity KW 42
Average heating input power KW 9.2
Rated heating input current A 18
Max outlet water temp °C 35
COP - 4.5
Power V/Hz 380/50
Noise Db(a) 60
Dimension W*D*H mm 1450*760*1060mm
Packing size W*D*H mm 1500*810*1100mm
Unit weight KG 300
Refrigerant - R417A/R407C/R404A
Working air temp range - (-20°C)—45°C
compressor Type - Danfoss/Copeland
Air source heat exchanger Type - Finned heat exchanger
Fan Type - axial flow fan
Hot water side heat exchange Type - Titanium heat exchanger
Water flow L/H 11000L/h
Water pressure down Kpa 40
Pipe size DN 63
-

-
