1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
1/2.7 2.8mm F1.2 3Megapixel M12x0.5 mount MTV IR lens for IMX322/IMX290/OV2715/AR230
Specifications
Place of Origin :
China
Model Number :
12702812MP-M12
Packaging Details :
Standard
Delivery Time :
2-7 work days
Supply Ability :
Samples available
Payment Terms :
T/T, Western Union, Moneygram, Paypal
Brand Name :
CCOM LENS
MOQ :
100pcs
Video Lens :
M12 Mount Board Lens
Resolution :
3MP
FOV(D*H*V) :
IMX322 126°x108°x59°, IMX290 132°x113°x61°, OV2715 137°x117°x63°, AR0230 137°x117°x63°
Lens Constructure :
7G
Description

Star Light/Low Light 1/2.7" 2.8mm F1.2 3MP M12x0.5 mount 137degree wide angle lens IR CCTV Lens for HD 1080P cameras, 2.8mm S mount MTV Lens for IMX322/IMX290/OV2715/AR0230 etc. sensor, day/night vision lens

Model 12702812MP-M12(B) (new model, better night vision)
IMAGE FORMAT 1/2.7” CCD/CMOS (Φ6.9mm)
FOCAL LENGTH 2.8mm
F.O.V (DxHxV) IMX322 126°x108°x59°, IMX290 132°x113°x61°, OV2715 137°x117°x63°, AR0230 137°x117°x63°
RESOLUTION 3MP
APERTURE F1.2
TV DISTORTION <-16%
MOUNT M12×0.5
IRIS Fixed
M.O.D. 0.3m
B.F.L. 5.1mm (in air)
T.T.L. 22.5mm (in air)
CONSTRUCTURE 7G
DIMENSION Φ15×17.4mm
NET WEIGHT 6g
OPERATING TEMP. -20℃ ~ 60℃

Model 12702812MP-M12(V1)
IMAGE FORMAT 1/2.7” CCD/CMOS (Φ6.9mm)
FOCAL LENGTH 2.8mm
F.O.V (DxHxV) IMX322 127°x108°x41°, IMX290 132°x112°x60°, OV2715 139°x116°x63°, AR0230 139°x116°x63°
RESOLUTION 3MP
APERTURE F1.2
TV DISTORTION <-16%
MOUNT M12×0.5
IRIS Fixed
M.O.D. 0.3m
B.F.L. 5.2mm (in air)
T.T.L. 22.8mm (in air)
CONSTRUCTURE 7G
DIMENSION Φ15×17.6mm
NET WEIGHT 6g
OPERATING TEMP. -20℃ ~ 60℃

Tips:

- IR-cut filter switch/IR-cut holder optional

- f2.8mm/3.6mm/6mm option

- M12/CS mount option

- For more lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com
