1/4 0.69mm F2.3 Megapixel M8 mount 220degree IR-Cut Fisheye Lens for OV9281
1/4 0.69mm F2.3 Megapixel M8 mount 220degree IR-Cut Fisheye Lens for OV9281
1/4 0.69mm F2.3 Megapixel M8 mount 220degree IR-Cut Fisheye Lens for OV9281
1/4 0.69mm F2.3 Megapixel M8 mount 220degree IR-Cut Fisheye Lens for OV9281
Specifications
Place of Origin :
China
Model Number :
14069MPF-M8
Packaging Details :
Standard
Delivery Time :
R&D stage
Supply Ability :
Samples NOT available
Payment Terms :
T/T, Western Union, Moneygram, Paypal
Brand Name :
CCOM LENS
MOQ :
100pcs
Board Lens :
M8 Mount Fisheye Lens
Resolution :
Megapixel
FOV :
220degree
Materials :
Metal + Glass
Description

High Definition Fisheye Lens

● High resolution

● Various application meet your requirements

● Compact design with cost-effective performance

● Custom design

● Super wide-angle with FOV up to 220° for panoramic surveillance
● Sharp image quality for multi-mega pixels cameras
● Suitable for various image frame
● IR cut option

1/4" 0.69mm F2.3 Megapixel M8 mount 220degree IR-CUT Fisheye Lens forOV9281, suitable for 360 VR Camera, Drone UAV lens

MODEL 14096MPF-M8
IMAGE FORMAT 1/4" 3.8x2.4, 4.5mm (HxV, D)
FOCAL LENGTH(mm) 0.96
F.O.V. 220°(D)*220°(H)*220°(V)
RESOLUTION MP
F-THETA DISTORTION <-10%
APERTURE F2.3
MOUNT(mm) M8
IRIS Fixed
M.O.D.(mm) 0.1
B.F.L.(mm) 1.17mm (with 0.3mm filter + 0.4mm C.G)
T.T.L.(mm) 13.0mm (with 0.3mm filter + 0.4mm C.G)
R.I. >60%
Max. CRA 5.3°
DIMENSION(mm) Φ19.2x11.83 (without outside cover)
LENS COMPOMEMT 6-5

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com
