Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Specifications
Place of Origin :
Japan
Brand Name :
LG Display
Certification :
RoHS Compliant
Model Number :
LB121S03-TL04
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
Standard Packaging
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000
Panel Size :
12.1 INCH
Resolution :
800(RGB)×600 , SVGA
Panel Model :
LB121S03-TL04
Brand :
LG
Description

Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement

1,LG Display LB121S03-TL04 Application Details

Basic Detail : Manufacturer Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement Model Name LB121S03-TL04
Panel Type a-Si TFT-LCD , LCM Another Name LB121S03 (TL)(04)
Panel Size 12.1 inch Designed For
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Maximum Ratings : OP Temperature -10 ~ 70 °C ST Temperature -30 ~ 80 °C
Vibration Level - RoHS Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
Features :
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
  • Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement

2,LG Display LB121S03-TL04 Optical Details

Basic Information : Luminance 400 cd/m² (Typ.) Contrast Ratio 600 : 1 (Typ.) (Transmissive)
Good View at - Response Speed 10/20 (Typ.)(Tr/Td) (ms)
Viewing Angle 70/70/55/65 (Typ.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.305; Wy:0.320 Support Color 262K/16.7M (6-bit / 6-bit + Hi-FRC)
Gamut 72% NTSC (CIE1931) White Variation 1.25/1.45 (Typ./Max.)(5 points)

3,LG Display LB121S03-TL04 Mechanical Details

Pixel Features : Number of Pixel 800(RGB)×600 [SVGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.1025×0.3075 mm Pixel Pitch(W×H) 0.3075×0.3075 mm
Physical Size : Active Viewing 246(W)×184.5(H) mm Overall Dim. 276(W)×209(H) mm
Bezel Opening - Overall Depth 10.6 (Max.) mm
Outline Features : Form Shape Flat Rectangle Display Orientation Landscape type
Aspect Ratio(W:H) 4:3 Outline Style -
Fixation : Face mounting holes (4-Φ3.4) on left, right bezel
Other Detail : Mass 600g (Max.) Surface Antiglare

4,LG Display LB121S03-TL04 Electronics Details

Refresh Rate : 60Hz
Reverse Scan : No
Total Power Consumption : 5.0W (Typ.)

5,LG Display LB121S03-TL04 Interface Details

Signal Electrical : Input Current 240/290mA (Typ./Max.) Input Voltage 3.3V (Typ.)
Consumption 0.80/0.96W (Typ./Max.) Signal Interface LVDS (1 ch, 6/8-bit)
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JAE FI-XB30SL-HF10 1 pcs 1.0 mm 30 pins

6,LG Display LB121S03-TL04 Lightting Details

Lamp Features: Lamp Type WLED Exchange - Position Edge light type
Amount - Lamp Shape - Life 50K(Min.) (Hours)
Interface Features : Position - Physical Type Included in panel signal interface
Backlight Driver : Embedded (LED Driver)
Driver Electrical : Input Current 350/400mA (Typ./Max.) Input Voltage 12.0V (Typ.)
Consumption 4.2/5.0W (Typ./Max.)

7,LG Display LB121S03-TL04 Packing Details

Package Box : Amount Size (L×W×H) Weight
16 pcs / box 425×328×350 mm

-

Detail picture for Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement

Lb121s03-tl04 12.1 Inch Lcd Screen Display Panel Repair Replacement
