Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Specifications
Place of Origin :
TAIWAN
Brand Name :
AUO
Certification :
RoHS Compliant
Model Number :
G085VW01 V3
MOQ :
5 Pcs
Price :
Pls Contact sales team
Packaging Details :
Standard Packaging
Delivery Time :
1 day
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000pcs
Vertical Frequency :
60Hz
Brightness :
200 cd/m² (Typ.)
Panel Size :
8.5 inch
Dot Resolution :
800(RGB)×480 (WVGA)
Description

Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)

Basic Information

Panel Brand : Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Panel Model : G085VW01 V3
Model Alias : G085VW01 V.3
Panel Type : a-Si TFT-LCD , Panel
Application :
  • Original AUO G085VW01 V3 8.5 inch LCD Panel Types with 200 cd/m² (Typ.)
Operating Temperature : -20 ~ 70 °C
Storage Temperature : -20 ~ 70 °C

Mechanical Features

Panel Size : 8.5 inch
Dot Resolution : 800(RGB)×480 (WVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 109 PPI
Aspect Ratio : 15:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.077×0.231 mm (H×V)
Pixel Pitch : 0.231×0.231 mm (H×V)
Weight : 320g (Typ.)
Surface : Antiglare, Hard coating (3H)
Active Area : 184.8×110.88 mm (H×V)
Bezel Area : 189.8×115.88 mm (H×V)
Outline Dimension : 210×134 mm (H×V)
Outline Depth : 10.0±0.5 mm
Holes & Brackets : Rear mounting holes
Landscape or Portrait : Landscape type
Touch Panel : Without

Optical Features

Display Mode : TN, Normally White, Transmissive
Brightness : 200 cd/m² (Typ.)
Contrast Ratio : 500 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Color Gamut : 50% NTSC (CIE1931)
Response Time : 20/10 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D)
White color Chromaticity : Wx:0.300; Wy:0.320
White Variation : 1.33/1.43 (Typ./Max.)(9 points)

Pls check the below LCD panel.If you need any other LCD display.pls contact with us:

KCG057QV1DB-G52 Kyocera 5.7" 320×240
KG057QV1CB-G001 Kyocera 5.7" 320×240
KCG057QV1EA-G050 Kyocera 5.7" 320×240
KG057QV1CB-G00 Kyocera 5.7" 320×240
KCG057QV1DC-G501 Kyocera 5.7" 320×240
KCS057QV1BR-G21 Kyocera 5.7" 320×240
KCS072VG1MF-G40 Kyocera 7.2" 640×480
KCS072VG1MB-G60 Kyocera 7.2" 640×480
KCS072VG1MB-G42 Kyocera 7.2" 640×480
KCS072VG1MA-A00 Kyocera 7.2" 640×480
KCS057QV1AA-A03 Kyocera 5.7" 320×240
KCS057QV1BK-G20 Kyocera 5.7" 320×240
LMBGAT032G27CKS NAN YA 5.7" 320×240
LMBGAZ032P27CKT NAN YA 5.7" 320×240
LMBGAT032G27CK NAN YA 5.7" 320×240
LM7M632R SHARP 6.5" 640×240
LM64P30R SHARP 9.4" 640×480
LM320195 SHARP 5.7" 320×240
LM320194 SHARP 5.7" 320×240
LM24013W SHARP 4.6" 240×64
LM213XB KOE 5.8" 256×64
LM065HB1T01 SHARP 6.5" 640×240
KHS072VG2AB-G01 Kyocera 7.2" 640×480
KG057QV1CA-G60 Kyocera 5.7" 320×240
KG057QV1CA-G020W Kyocera 5.7" 320×240
G242CX5R1AC SII 5.5" 240×128
EW50397BCW EDT 4.7" 320×240
EW32F41BMW EDT 5.7" 320×240
EG9015D-NZ-3 Epson 8.4" 640×480
LM32019P5R SHARP 5.7" 320×240
EG2402S-AR Epson 6.2" 240×64
EDMGRB7KAF Panasonic 12.1" 800×600
DMF6104NB-FW Kyocera 5.3" 256×128
DMF5001NYL-ACE Kyocera 4.7" 160×128
K6483L-FF CITIZEN 7.8" 640×480
AG-320240A7STQW08H-A(N)(R) AMPIRE 5.7" 320×240
