350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
Specifications
Place of Origin :
JAPAN　
Brand Name :
Tianma
Certification :
Standard Certification
Model Number :
TM035KDH05
MOQ :
1PCS
Price :
Pls Contact sales team
Packaging Details :
Standard Packaging
Delivery Time :
2-3 days
Payment Terms :
T/T , Paypal, Western Union Escrow etc.
Supply Ability :
5000
Resolution (pixel) :
320*240
Viewing Angle (R/L/U/L) :
50/70/70/70
Contrast Ratio :
350:1
Backlight :
QVGA
Display Mode: :
TN, Normally White, Transmissive
Description

Quick Details :

350:1 Contrast 320*240 Resolution TIANMA 3.5 inch 60PIN TFT LCD Screen with Touch Panel TM035KDH05 QVGA 320(RGB)*240

Specifications

TM035KDH05
1.Ideal for general applications
2.Wide screen
3.CCFL BL
4.Lower price provided




Panel Brand: TIANMA
Panel Model: TM035KDH05
Panel Type: a-Si TFT-LCD, Panel
Panel Size: 3.5 inch
Resolution: 320(RGB)*240, QVGA
Display Mode: TN, Normally White, Transmissive
Surface: Clear, Hard coating (3H)
Brightness: 420 cd/m2 (Typ.)
Contrast Ratio: 350:1 (Typ.)
Display Color: 16.7M
Response Rime: 25 (Typ.) (Tr+Td) (ms)
Viewing Angle: 60/60/50/60 (Typ.) (CR≥10) (L/R/U/D)
Frequency: 60Hz
Lamp Type: 6S1P WLED
Signal Interface: Digital RGB (8/24-bit)+SPI, CCIR601/656
Input Voltage: 3.3V (Typ.)
RoHS 350:1 TIANMA 3.5 inch lcd panel type with Touch TM035KDH05 320(RGB)*240,QVGA
Application: All Digital Still Camera Panel, All Digital Video Camera Panel

TIANMA TM035KDH Series Model

Panel Model Size Resolution cd/m2 C/R Backlight Interface
TM035KDH10 3.5" 320×240 330 500:1 WLED Parallel/Serial
TM035KDH09 3.5" 320×240 300 350:1 WLED Parallel/Serial
TM035KDH08 3.5" 320×240 200 300:1 WLED Parallel/Serial
TM035KDH05 3.5" 320×240 420 350:1 WLED Parallel/Serial
TM035KDH04-09 3.5" 320×240 650 500:1 WLED Parallel/Serial
TM035KDH04 3.5" 320×240 420 500:1 WLED Parallel/Serial
TM035KDH03-79 3.5" 320×240 300 500:1 WLED Parallel/Serial
TM035KDH03-36 3.5" 320×240 300 500:1 WLED Parallel/Serial
TM035KDH03 3.5" 320×240 300 500:1 WLED Parallel/Serial
TM035KDH02 3.5" 320×240 200 350:1 WLED Parallel/Serial
TM035KDH01 3.5" 320×240 420 350:1 WLED Parallel/Serial

3.5", 320×240, Parallel/Serial, 2D, WLED, Flat, Panel Hot Model

Panel Model Size Resolution cd/m2 C/R Backlight Interface
LQ035NC111 3.5" 320×240 250 400:1 WLED Parallel/Serial
LQ035NC211 3.5" 320×240 200 400:1 WLED Parallel/Serial
TM035KDH03 3.5" 320×240 300 500:1 WLED Parallel/Serial
TM035KDH03-79 3.5" 320×240 300 500:1 WLED Parallel/Serial
LB035Q02-TD01 3.5" 320×240 300 400:1 WLED Parallel/Serial
TM035KBH02-09 3.5" 320×240 350 500:1 WLED Parallel/Serial
TM035KBH02 3.5" 320×240 350 500:1 WLED Parallel/Serial
LB035Q04-TD08 3.5" 320×240 370 400:1 WLED Parallel/Serial
TM035KBZ17 3.5" 320×240 300 400:1 WLED Parallel/Serial
TM035KDH05 3.5" 320×240 420 350:1 WLED Parallel/Serial
