LG Display 15.1inch LM151X1 LCD Panel
LG Display 15.1inch LM151X1 LCD Panel
Specifications
Place of Origin :
Japan
Brand Name :
LG Display
Certification :
RoHS Compliant
Model Number :
LM151X1
MOQ :
1 Pcs
Price :
Pls Contact sales team
Packaging Details :
MODULE
Delivery Time :
stock
Payment Terms :
T/T , Paypal, Western Union ,Escrow etc.
Supply Ability :
1000
Panel Model :
LM151X1
Panel Brand :
LG Display
Descrition :
a-Si TFT-LCD ,15.1 inch, 1024×768
Panel Type :
a-Si TFT-LCD
Description

LG Display 15.1inch LM151X1 LCD Panel

Specification for LM151X1:

LM151X1 Basic Information

Panel Model

LM151X1

Panel Brand

LG Display

Descrition

a-Si TFT-LCD ,15.1 inch, 1024×768

Panel Type

a-Si TFT-LCD

LM151X1 Mechanical Features

Dot Resolution

1024(RGB)×768 (XGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

84 PPI

Aspect Ratio

4:3 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.100×0.300 mm (H×V)

Pixel Pitch

0.300×0.300 mm (H×V)

Surface

Antiglare, Hard coating (3H)

Active Area

307.2×230.4 mm (H×V)

Bezel Area

311.2×234.4 mm (H×V)

Outline Dimension

352.6×264.6 mm (H×V)

Outline Depth

16.0 (Typ.) mm

Holes & Brackets

Face mounting holes (2-Φ3.4, 2-R1.7)

Landscape or Portrait

Landscape type

Touch Panel

Without

LM151X1 Optical Features

Display Mode

TN, Normally White, Transmissive

Display Color

16.7M (8-bit)

Sunlight Readable

N

LM151X1 Electronics Feature

Vertical Frequency

60Hz

LM151X1 Backlight System

Lamp Position

Edge light type (Top and Bottom)

Lamp Type

CCFL

Lamp Amount

2 pcs

Lamp Shape

Straight

Lamp Life Time

40K(Typ.) (Hours)

Lamp Voltage

570/585/685V (Min./Typ./Max.)

Lamp Current

3.0/8.0/9.0mA (Min./Typ./Max.)

Lamp Operating Frequency

30/50/80KHz (Min./Typ./Max.)

Lamp Startup Voltage

1290/1660V (Min.)(Ta=+25/0℃)

Interface Type

Connector

Lamp Driver Board

No

LM151X1 Signal Interface

Signal Category

LVDS

Signal Class

LVDS (1 ch, 6-bit)

Input Voltage for Panel

3.3/5.0V (Typ.)(VCC/VDD)

Input Current for Panel

230/360mA (Typ.)(ICC/IDD)

Interface Type

Connector

Signal Interface

JAE - FI-WE21P-HF, Pitch:1.25 mm, Pin:21 pins
