Power Led Driver IC TLE6284G - Technologies AG - H-Bridge Driver IC
Power Led Driver IC TLE6284G - Technologies AG - H-Bridge Driver IC
Specifications
Place of Origin :
PHILIPPINE
Brand Name :
Technologies AG
Certification :
Lead free / RoHS Compliant
Model Number :
TLE6284G
MOQ :
50
Price :
Contact for Sample
Packaging Details :
Contact for Sample
Delivery Time :
Within 3days
Payment Terms :
T/T in advance, Paypal, Western Union
Supply Ability :
5000
Description

Quick Detail:

H-Bridge Driver IC

Description:

H-bridge driver IC for MOSFET power stages with multiple protection functions.

The TLE6184G is very similar to the TLE6281G. The major difference is that the Short Circuit protection level of the TLE6284G can be adjusted by external resistors or even disabled. The pin outs are different as well.

Applications:

• Compatible to very low ohmic normal level input N-Channel MOSFETs

• PWM – DIR - Interface

• PWM frequency up to 50kHz

• Operates down to 7.5 V supply voltage

• Low EMC sensitivity and emission

• Adjustable dead time with shoot through protection

• Deactivation of dead time and shoot through protection possible

• Short circuit protection for each Mosfet can be disabled and adjusted

• Driver undervoltage shut down

• Reverse polarity protection for the driver IC

• Fast disable function / Inhibit for low quiescent current

• Input with TTL characteristics

• 2 bit diagnosis

• Thermal overload warning for driver IC

• Shoot through protection

• Integrated bootstrap diodes

Specifications:

Datasheets

TLE6284G

Product Photos

20-SOIC 0.295

Standard Package

1

Category

Integrated Circuits (ICs)

Family

PMIC - Motor and Fan Controllers, Drivers

Series

-

Packaging

Cut Tape (CT)

Motor Type - Stepper

Bipolar

Motor Type - AC, DC

Brushed DC

Function

Driver - Fully Integrated, Control and Power Stage

Output Configuration

Pre-Driver

Interface

Parallel

Applications

General Purpose

Current - Output

-

Voltage - Supply

7.5 V ~ 60 V

Voltage - Load

-

Operating Temperature

-40°C ~ 150°C

Mounting Type

Surface Mount

Package / Case

20-SOIC (0.295", 7.50mm Width)

Supplier Device Package

PG-DSO-20

Other Names

TLE6284GCT

Competitive Advantage:

Warranty :180days for all goods

Free shipping:Order over $600 win a free shipment fee:goods weight below 3Kg.

Mega Source Electronics stocks components ready to ship. Hard to find, obsolete and highly allocated integrated circuits and semiconductors are all can be found by us.

Mega Source Electronics has established a well-developed logistics system and global logistics network, which can guarantee our service very quick, convenient and efficient.
