Home Solar Energy Storage System 5KW With MPPT Charging Inverter 5KWH LFP Battery
Home Solar Energy Storage System 5KW With MPPT Charging Inverter 5KWH LFP Battery
Specifications
Brand Name :
Melin Sunergy
Model Number :
EOH05C
Place of Origin :
China
Certification :
CE ,FCC ,UKCA
MOQ :
1
Delivery Time :
15 days
Payment Terms :
TT ,West Union
Supply Ability :
1000pcs per month
Storage Temperature Range :
-25℃ ～ 60℃
Ingress Protection Rating :
IP20
Output Frequency :
50HZ/60HZ
PV charging Type :
MPPT
PV Operating Voltage Range :
120～500V
Parallel Quantity :
4
Rated Output Power :
5KW
MPPT Voltage Range :
120～450V
Description

5KW Solar home energy storage systems with MPPT Charging inverter 5KWH LFP battery

Inverter model
Item No. EOH05C
Rated Output Power 5000W
Max. Peak Power 10000KVA
Load Capacity of Motor 4HP
Wave Form Pure Sine Wave
Rated Output Voltage 230Vac (single phase)
Solar Charge Type MPPT
Max.Input Solar Power 5500W
Max. Solar Open Circuit Voltage 500V
GRID/GENERATOR INPUT Voltage Range 90~280Vac
Max. Solar Charging Current to battery 100A
Max. Grid/Generator Charging Current to battery 60A
Gross Weight 19.6kg(43.2lb)
Dimension 655*353*210 (2.14*1.15*0.69ft)
Protection Degree IP20
Cooling Mode Natural cooling
Safety EN61000, C2 , CE(EN62109-1)
Battery Model
Battery Power 5.12KWH
Rated Voltage 51.2V
Rated Capacity 100Ah
Battery Type LiFePO4
Cycling Lifespan 6000
Max. Parallel Capacity 9 units (up to 46.08kWh)
Gross Weight 46.6kg(102.735lb)
Dimension 655*353*210 (2.14*1.15*0.69ft)

5kw system off-grid solar, 5kw solar system daily production, 5kw solar power system

Applications:

The EOH48-5.0 solar energy storage system is a reliable and efficient solution for home solar power systems. It has a PV charging current range of 0-80A, making it suitable for a variety of solar panels. The battery module capacity is 100Ah/51.2V of each, ensuring a long-lasting and stable power supply. With a rated output power of 5KW, this system can power a variety of household appliances and devices.

The EOH48-5.0 solar energy storage system has an ingress protection rating of IP20, ensuring that it is resistant to dust and water. This makes it suitable for indoor use, but not recommended for outdoor use. The battery type used in this system is LiFePO4, which is known for its high energy density, long cycle life, and safety.

This solar energy storage system is perfect for various occasions and scenarios. It is suitable for home solar power systems, providing a reliable and sustainable power source for households. It can also be used for backup power during power outages, ensuring that critical appliances and devices remain operational. The EOH48-5.0 is also suitable for small businesses, providing an affordable and efficient energy solution for the workplace.
