Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System
Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System
Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System
Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System
Specifications
Brand Name :
HYNAMO/OEM
Model Number :
BW 3012-500
Certification :
CE, RoHS, ISO9001, NSF
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30000 PCS /Month
Delivery Time :
depend on quantity
Packaging Details :
35.00cm*35.00cm*37.00cm
Type :
3012-500
Salt Rejection Rate :
97%
Capacity :
500GPD
Warranty :
3 Years
Weight :
0.5KG
Working up :
1000TDS
Recovery :
50%
Function :
Water Purification Plant
Description

Domestic / Commercial BW 3013 - 500 Gpd High Flow RO Membrane

The reverse osmosis membrane is widely used in electric power, petrochemical industry, steel, electronics, medicine, food and beverage, municipal and environmental protection and other fields. It plays an important role in seawater and brackish water desalination, boiler water supply, industrial pure water and electronic grade ultra pure water preparation, drinking water production, wastewater treatment and special separation processes.

The reverse osmosis membrane can intercept various inorganic ions, colloidal substances and macromolecular solutes in the water, so as to obtain purified water. It can also be used for pre-concentration of macromolecular organic matter solutions. Due to the simple process of reverse osmosis and low energy consumption, it has developed rapidly in the past 20 years. It has been widely used in seawater and brackish water (see brine) desalination, boiler water softening and wastewater treatment, and combined with ion exchange to produce high-purity water. and separation and concentration of biological agents.

Product Description

Model 3012-500
Operation Pressure (psi) 90
Highest Operation Pressure (psi) 100
Application For Pure water producing
Test Solution Concentration (ppm) 250
Recovery Rate % 50%±5
Stable Rejection Rate % 97
Flow Rate (GPD) 500
Max. Pressure Difference (psi) 15
Max. Feed Water SDI 5
Acceptance capacity of free Chlorine ≤0.1
PH Range of feed water as continious operation 2-11

Operating Limit:

Maximum Operating Temperature 113ºF(45ºC)
Maximum Working Pressure 150psi(10bar)
Maximum Feed Flow 2.0gpm(7.6lpm)
Continuously operating PH range a 2-11
Short wash PH range (30min) b 1-13
Maximum feed water SDI SDI 5
Tolerance Of Free Chlorine <0.1ppm


Note:1. The Max. continous operation temperature is 35ºC when PH rate over 10.

2. In certain conditions,if would cause membrane breakage if the free chlorine or the other oxidant in feedwater.The production quality guarantee range is notincluded membrane breakage by oxiadation.

Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System

Procedures

Domestic Commercial Ro Membrane BW 3013 500 Gpd Reverse Osmosis System

FAQ:
Q: How to buy your products?

A: we need some essential information include sewage sources, sewage quality ( COD, BOD,SS),Required Filtered water quality, designed technological process, site engineering conditions (contact us for details),then we will design the uitable solutions for you and prepare to give you best price.

Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balanced against the copy of B/L.

Q: What is the delivery time?
A: Usually within 15days. Also depends on order quantities.

Q: Can the package be customized by our own logo ?
A: Yes, the package can be customized your logo, but the MOQ will be higher for which we can discuss as per the specific orders.

Q: How to install after the products arriving destination?
A: We will provide detailed illustrations to you. And we can also provide guide to your workers how to use it and how to maintain
it.

Q:What's the certification do you have?
A: We have NSF, ISO9001, OHSAS18001, ISO14001 Certifications.
