400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier
Specifications
Brand Name :
Hynamo/OEM/ODM
Model Number :
3013-800 BW
Certification :
CE, RoHS, ISO9001, NSF
Place of Origin :
Hangzhou city, Zhejiang, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Pieces per Month
Delivery Time :
depend on quantity
Packaging Details :
35.00cm*35.00cm*37.00cm
Type :
RO Membrane Element
Salt Rejection Rate :
95%
Capacity :
3.04m³/d
Warranty :
3 Years
Weight :
0.6KG
Working up :
1000ppm
Recovery :
50%±15%
Function :
Water Purification Plant
Applicable Industries :
Hotels, Building Material Shops, Food & Beverage Factor
Description

Water Filter Commercial Purifier Hynamo 3013-800 GPD RO Membrane

Membranes are used more and more often for the creation of process water from groundwater, surface water or wastewater. Membranes are now competitive for conventional techniques. The membrane separation process is based on the presence of semi permeable membranes.

RO system membrane is made of the sedi-permeable membrane with the 0.1mm filtration precision for separating and removing the dissolved solids, organics, bacteria etc. According to the water output capacity, the different large flow membrane is available as follows: 300G, 400G,500G,600G,700G,800G.

Product Specification

Model 3013-800
Performance Stable Desalination Rate% 96
Average permeate Flow GPD 800
Test Conditions Test Pressure 0.6Mpa
Test Temperature 25±1ºC
Test Solution(NaCl) 250±50ppm
Test solution pH 6.5-7.5
Single Membrane Element Recovery Rate 50±5%

Performance and test conditions

model Stable rejection rate(%) average permeate flowGPD(m3/d) test condition
operation pressure psi(Mpa) test liquid NaCl(ppm) recovery rate (%)
2812-300 97 300(1.14) 90(0.61) 500 50
2812-400 95 400(1.52) 90(0.61) 500 50
3013-400 95 400(1.52) 100(0.7) 500 50
3013-600 95 600(2.28) 100(0.7) 500 50
3013-800 95 800(3.04) 100(0.7) 500 50

Note: Single membrane permeate flow change in the range of ±15%

Test Conditions

Test Pressure 100psi( 0.7Mpa)

Temperature 25ºC

Concentration of Testing Solution (NaCl) 500ppm

Testing Solution PH 2-11

Note:

1. The Max. continous operation temperature is 35ºC when PH rate over 10.

2. In certain conditions,if would cause membrane breakage if the free chlorine or the other oxidant in feedwater.The production quality guarantee range is notincluded membrane breakage by oxiadation.

Dimension of Membrane Element

400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier

3013-800: A:13.0inch B:3.0inch C:0.68inch D:0.75inch E:11.5inch

HN-JCM brand membrane element produced by world advanced membrane technology and fully automatic production equipment. It can operation under the extra low pressure. Our membrane suitable for household water purifiers, hospitals, laboratory pure water, treatment municipal tap water, well water and other low salinity water sources.

400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier

400 Gpd 500 Gpd 800 GPD Commercial Ro Membrane And Filter Water Purifier

FAQ:


Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balanced against the copy of B/L.

Q: What is the delivery time?
A: Usually within 15days. Also depends on order quantities.

Q: Can the package be customized by our own logo ?
A: Yes, the package can be customized your logo, but the MOQ will be higher for which we can discuss as per the specific orders.

Q: How to install after the products arriving destination?
A: We will provide detailed illustrations to you. And we can also provide guide to your workers how to use it and how to maintain
it.

Q:What's the certification do you have?
A: We have NSF, ISO9001, OHSAS18001, ISO14001 Certifications.
