Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
Specifications
Brand Name :
UPK
Model Number :
U015
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1 Pc
Price :
Negotiation
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
2000 Pcs per month
Delivery Time :
20-30 Days
Packaging Details :
1 PC Per wooden box
Item Name :
Big flow filter housing
Material :
304 316L
Style :
Vertical & Horizontal
Inlet & Outlet :
Flange, Quick Coupler
Application :
Large liquids filtration
Others :
Design drawing if need
Description

Vertical and horizontal style stainless steel filter housing for high flow filter

Description

In order to adapt to Mid- & Big- system, we designed horizontal style high flow filter housings, according to principle of fluid dynamics, add its more reasonable inner construction, it can be suitable to systems when its flow rate >=1000T / Hour. Because of its easy-to-install & easy-to- change-outs, this style products is optical choice of many water treatment clients.

Specification

Table 1, Surface Treatment

Polishing Type Physical / Grit Blast
Polishing Rating I-0.6μm / O-0.8μm

Table 2, Operational Environment

Pressure 0.6Mpa /1.0Mpa
Max Temp. 130℃ (266℉)
Sterilization 121℃/30Min.

Table 3, Material

Housing 304, 316L
Vent/Drain Valve 304, 316L
Tri-Clasp 304
Stand Bar 304
O-ring/Gasket Silicone, Viton, EPDM

Table 4, Connection

Cylinder Eye Bolt
Inlet/outlet Flange
Vent Quick coupler / Flange
Drain Quick coupler / Flange
Gauge Flange / M14×1.5


Optional Filter Cartridge

D/φ 150 / 152 / 165mm
Style Pall / Parker / 3M
Bag filter cartridge
Length 20” 40” 60”

Application

It is wildly used in high flow industries, especially in water treatment field, Eg.: desalination plant pre-filtration, sewage treatment, swimming pool water circle, etc.

Feature & Benefits

1, Various connector

2, Reasonable frame

3, Universal design

4, All-in-one process

Ordering Information

Vertical / Horizontal Style Stainless Steel Housing Filter High Flow Filtration
