Food Grade 5 Micron PP Pleated Filter Cartridge For Prefiltration Beverage / Water
Food Grade 5 Micron PP Pleated Filter Cartridge For Prefiltration Beverage / Water
Food Grade 5 Micron PP Pleated Filter Cartridge For Prefiltration Beverage / Water
Food Grade 5 Micron PP Pleated Filter Cartridge For Prefiltration Beverage / Water
Specifications
Brand Name :
Upick
Model Number :
U-DLL004
Certification :
FDA
Place of Origin :
China
MOQ :
50PCS
Price :
Negotiation
Payment Terms :
LC TT PAYPAL
Supply Ability :
12000 PCS per Month
Delivery Time :
15-20 Workdays
Packaging Details :
Inner box & Carton
Item Name :
soft net PP high flow filter
Material :
PP
Pore Size :
5 micron
Length :
20 inch
Packing :
inner box
Others :
Super service life
Description

5 micron 40 inch PP high flow filter cartridge for soft net out cage

Description

UPK high flow filter cartridges are plus large diameter pleated cartridge ,significantly reducing the number of cartridges required as well as the housing size.The filter cartridge has flow capacity equal to 10 standard 40 inch long cartridges that would reduce upfront capital costs .

Specification

Micron rating 1, 5, 10, 15, 20, 40, 70, 100μm
Dimension Outside diameter 6"(152mm)
Inside diameter 3.5"(89mm)
Length 20", 40", 60"
Max. Operating temperature Glass fibers membrane 121℃
PP microfiber 82℃
Max. Operating pressure 0.24Bar@121℃
0.24Bar@82℃
Surface area 24 ft2. (2.2 m2) per 20" element
49 f 2. (4.6 m2) per 40" element
73 ft2. (6.8 m2) per 60" element
Maximum flow rates 20" element up to 40 m3/hr
40" element up to 70 m3/hr
60"element up to 70 m3/hr
O-Rings material EPDM

Application

  • Potable Wate
  • Vegetable Oil
  • Waste water
  • Lubricants
  • Food and Beverage
  • Coolants

Benefits and Features

  • High flow capacity means fewer cartridges and less time to change
  • High flow capacity allows smaller housings
  • Built in handle makes change fast, easy and safe
  • O-ring seal assures filtration integrity
  • High surface area pleated design provides low pressure drop and long service life
  • Horizontal and vertical housings available for flow rates up to 3325gpm
  • Reduces process interruptions

Food Grade 5 Micron PP Pleated Filter Cartridge For Prefiltration Beverage / Water
