0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
Specifications
Brand Name :
Upick
Model Number :
U-ZD007
Certification :
FDA
Place of Origin :
China
MOQ :
50PCS
Price :
Negotiation
Payment Terms :
LC TT PAYPAL
Supply Ability :
120000 PCS per Month
Delivery Time :
15-20 Workdays
Packaging Details :
Inner box & Carton
Item Name :
215 nylon 66 filter element
Material :
Nylon 66
Pore Size :
0.2-50 micron
Length :
MTO size
Packing :
Vacuum packing
Others :
Round fins
Description

0.45 micron Nylon 66 membrane pleated filter cartridge for beer filtration

Description

TON66 Membrane Filter Cartridges are designed for sterilizing filtration, all nylon membrane used in the cartridges is selected for retention. Nylon is particularly suited for the filtration of solvents because of its broad compatibility and low level of extractable.

Constructional Materials

Filtering Media Nylon66 Membrane
Media Support Polypropylene
End Caps Polypropylene
Center Core Polypropylene
Support Cage PP or PP with SS lining
O-Ring Silicone, EPDM, Viton, FPM, Nitrile, etc.


Dimensions

Internal φ 32 mm
External φ 68 mm, 69 mm
Length 2.5~40 inch
Filtration Area >=0.65 m2


Service Condions

PH Value 6~13
Working Temp. <=65℃
Max. Temp. 90℃, △P<=0.1Mpa
Max. Differential 25℃, 0.42/0.21Mpa

Flow Rate / 10" Element with Water at 68 °F (20 °C)

0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process

Educt

Endotoxin < 0.25EU/ML

Extractive < 0.03g/10 inch filter cartridge

Applications

  • CPM
  • Buffer Solution
  • Eye Drops
  • LVP
  • Blood Products
  • Cell Culture

USP Biosafety & FDA Compliance

All the materials of the filter is non-toxic and meet the requirements for Biological Reactivity Tests in USP for Class VI – 121℃ Plastics. In addition, the materials meet the requirements listed by the FDA as appropriate for use in articles intended for repeated food contact as specified in Title 21 CFR section. The levels of bacterial endotoxins in aqueous extracts from the filters are below current USP limits as specified for WFI.

End Caps

0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process

0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process

Quality Assurance & Standards

Our goal is to ensure our customers the greatest possible value for their filtration cost. Our state of the art manufacturing facility and quality management system both meet ISO 9001:2008 standards. Each operation from assembly and test to cleaning, drying, and packaging is completed in appropriately rated clean rooms. A sophisticated MRP & ERP system collects and processes real time data from manufacturing centers and inspection points. This allows variable and attribute data to be quickly and easily analyzed driving constant improvements in both quality and cost.

Ordering Information

Cartridge order numbers have several variables from pore size to end cap type.

For instant, Nylon66 Membrane, 20 inch length, 0.20 micron rating, 226 w/fin end cap, without lining, Silicone O-rings.

Product Code =TON66200200CN1S

0.45 Micron Membrane Filter Cartridge Nylon 66 Material In Beer Production Process
