High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
Specifications
Brand Name :
Upick
Model Number :
U-ZD001
Certification :
FDA
Place of Origin :
China
MOQ :
10PCS
Price :
Negotiation
Payment Terms :
LC TT PAYPAL
Supply Ability :
120000 PCS per Month
Delivery Time :
15-20 Workdays
Packaging Details :
Inner box & Carton
Item Name :
APP filter element
Material :
PP
Pore Size :
0.45 or above
Length :
5, 10, 20, 30, 40 inch
Packing :
Vacuum plastic bag
Others :
Integrity test for each one
Description

Absolute accuracy APP 0.45 micron membrane pleated filter cartridge

Description

TZAPP series Membrane Filter Cartridge are manufactured for the specific needs in many high demand industry. it is the only type of absolute rate filter cartridge made from ultra-fine nano-fiber PP membrane from abroad. Each cartridge module is individually integrity tested, intensity tested before it is released from manufacture. The cartridge surface area, filter core design, pleat configuration, and pleat packing density have been optimized to provide increased cartridge life resulting in lower filtration operating costs. Stable construction ensures repeatable steaming and testing.

Constructional Materials

Filtering Media Nano-Fiber Polypropylene
Media Support Polypropylene
End Caps Polypropylene
Center Core Polypropylene
Support Cage Polypropylene
O-Ring Silicone, EPDM, Viton, FPM, etc.

Dimensions

Internal φ 32 mm
External φ 68 mm, 69 mm
Length 2.5~40 inch
Filtration Area >=0.6 m2

Service Condions

PH Value 1~14
Working Temp. <=55℃
Max. Temp. 80℃, △P<=0.1Mpa
Max. Differential 25℃, 0.42/0.21Mpa

Flow Rate / 10" Element with Water at 68 °F (20 °C)

High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag

Educt

Endotoxin < 0.25EU/ML

Extractive < 0.03g/10 inch filter cartridge

Applications

  • Pharmacy
  • Solvents
  • Ultra-Pure Water
  • Chemicals
  • Winery
  • Brewery

Features & Advantages

1, Latest and advanced PP membrane tech.

2, Reasonable core and cage design.

3, Optimum membranes compound mode.

4, Unique absolute rate PP filter cartridge.

5, Variety of end caps are optional.

6, Without any adhesive being used.

End Caps

High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag

High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag

Quality Assurance & Standards

Our goal is to ensure our customers the greatest possible value for their filtration cost. Our state of the art manufacturing facility and quality management system both meet ISO 9001:2008 standards. Each operation from assembly and test to cleaning, drying, and packaging is completed in appropriately rated clean rooms. A sophisticated MRP & ERP system collects and processes real time data from manufacturing centers and inspection points. This allows variable and attribute data to be quickly and easily analyzed driving constant improvements in both quality and cost.

Ordering Information

Cartridge order numbers have several variables from pore size to end cap type.

For instant, AP Grade PP Membrane, Absolute rate, 20 inch length, 0.20 micron rating, 226 w/fin end cap, without lining, Silicone O-rings.

Product Code =TZAPP200200CN1S

High Capacity 0.45 Micron PP Melt Blown Filter Cartridge With Vacuum Plastic Bag
