3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
3x27P 2.54 Mm Pitch Female Pin Connector IC 2.54 Mm Female Header Strip
Specifications
Brand Name :
Terastor
Model Number :
2.54-3*27P Female
Place of Origin :
CHINA
MOQ :
1000 PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100K PCS
Delivery Time :
2-3 DAYS
Packaging Details :
1000 PCS/Bag
Certification :
RoHS
Catalogue :
Female Header
Rows :
Three rows
Pitch :
2.54mm
Plastic height :
4.2mm
Pin length :
7.4mm
Jack diameter :
1.27mm
Jack structure :
3*27P
Jack type :
Round hole
Jack direction :
Top
Installation type :
In-line
Contact material :
Inner gold and outer tin
Plastic material :
PPS
Description

Terastor Round hole socket/Female Header 2.54mm 3*27P

Pin(outer sleeve):Brass,machined CuZn38Pb2
Plating(outer sleeve):
Tin Plated:2m/80pNI,5pm/200p"Sn
Gold Plated:2p"/80p~Ni,0.8p”gold
Plating(Contact ):2pm/80p"NI,gold or Tin platedInsuiator:PPS UL94V-0Cllp(Contact 6 Flnger):Beryllium copper,heat teated
Electrical:Current rating:3Amps/contact max.Contact resistance: mQ/contact
Insuiation resistance:>1000M0 at V-100VDleiectrle Withstanding Voltage:1000V AV Min
Operaling voltage:60VAC/DC
Mechanical:Average Insertlon force with steel pin of e0.66mm/0.38":<250gAverage withdrawal force with steel pin of e0.66mm/0.38":<70gMechanlcal lige cycle:min 200Operaling temperature:-40” C to+105”CSoldering temperature:+255%C
