Intel EP4CGX15BF14I7N Cyclone IV GX Field Programmable Gate Array FPGA Ic Microcontroller 72 552960 14400 169-LBGA
Intel EP4CGX15BF14I7N Cyclone IV GX Field Programmable Gate Array FPGA Ic Microcontroller 72 552960 14400 169-LBGA
Specifications
Brand Name :
Intel
Model Number :
EP4CGX15BF14I7N
Certification :
RoHS
Place of Origin :
United States
MOQ :
119 PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
3927 PCS
Delivery Time :
2-3 DAYS
Packaging Details :
119 PCS/Tape
Manufacturer :
Intel
Category :
FPGAs (Field Programmable Gate Array)
Product Number :
EP4CGX15BF14I7N
Series :
Cyclone® IV GX
Product Status :
Active
Number of LABs/CLBs :
900
Number of Logic Elements/Cells :
14400
Total RAM Bits :
552960
Number of I/O :
72
Voltage - Supply :
1.16V ~ 1.24V
Mounting Type :
Surface Mount
Operating Temperature :
-40°C ~ 100°C (TJ)
Package / Case :
169-LBGA
Supplier Device Package :
169-FBGA (14x14)
Base Product Number :
EP4CGX15
Description

EP4CGX15BF14I7N Cyclone® IV GX Field Programmable Gate Array (FPGA) IC 72 552960 14400 169-LBGA

Datasheet:EP4CGX15BF14I7N

Category FPGAs (Field Programmable Gate Array)
Mfr Intel
Series Cyclone IV GX
Package Tray
Product Status Active
Digi-Key Programmable Not Verified
Number of LABs/CLBs 900
Number of Logic Elements/Cells 14400
Total RAM Bits 552960
Number of I/O 72
Voltage - Supply 1.16V ~ 1.24V
Mounting Type Surface Mount
Operating Temperature -40°C ~ 100°C (TJ)
Package / Case 169-LBGA
Supplier Device Package 169-FBGA (14x14)
Base Product Number EP4CGX15

Preliminary Information

The CycloneTM field programmable gate array family is based on a 1.5-V, 0.13-µm, all-layer copper SRAM process, with densities up to 20,060 logic elements (LEs) and up to 288 Kbits of RAM. With features like phaselocked loops (PLLs) for clocking and a dedicated double data rate (DDR) interface to meet DDR SDRAM and fast cycle RAM (FCRAM) memory requirements, Cyclone devices are a cost-effective solution for data-path applications. Cyclone devices support various I/O standards, including LVDS at data rates up to 311 megabits per second (Mbps) and 66-MHz, 32-bit peripheral component interconnect (PCI), for interfacing with and supporting ASSP and ASIC devices. Altera also offers new low-cost serial configuration devices to configure Cyclone devices.

Features

■ 2,910 to 20,060 LEs, see Table 1

■ Up to 294,912 RAM bits (36,864 bytes)

■ Supports configuration through low-cost serial configuration device

■ Support for LVTTL, LVCMOS, SSTL-2, and SSTL-3 I/O standards

■ Support for 66-MHz, 32-bit PCI standard

■ Low speed (311 Mbps) LVDS I/O support

■ Up to two PLLs per device provide clock multiplication and phase shifting

■ Up to eight global clock lines with six clock resources available per logic array block (LAB) row

■ Support for external memory, including DDR SDRAM (133 MHz), FCRAM, and single data rate (SDR) SDRAM

■ Support for multiple intellectual property (IP) cores, including Altera MegaCore functions and Altera Megafunctions Partners Program (AMPPSM) megafunctions

Data Picture:
Intel EP4CGX15BF14I7N Cyclone IV GX Field Programmable Gate Array FPGA Ic Microcontroller 72 552960 14400 169-LBGA
