ADM2587EBRWZ-REEL7 RS422 RS485 Digital Isolator Ic 2500Vrms 2 Channel 500kbps 25kV µS CMTI 20-SOIC 0.295
ADM2587EBRWZ-REEL7 RS422 RS485 Digital Isolator Ic 2500Vrms 2 Channel 500kbps 25kV µS CMTI 20-SOIC 0.295
Specifications
Brand Name :
ADI
Model Number :
ADM2587EBRWZ-REEL7
Certification :
RoHS
Place of Origin :
Analog Devices Inc.
MOQ :
400 PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
6K PCS
Delivery Time :
2-3 DAYS
Packaging Details :
400 PCS/Tube
Category :
Digital Isolators
Mfr :
Analog Devices Inc.
Series :
ADM2587E
Technology :
Magnetic Coupling
Type :
RS422
Number of Channels :
2
Inputs - Side 1/Side 2 :
1/1
Channel Type :
Unidirectional
Voltage - Isolation :
2500Vrms
Common Mode Transient Immunity (Min) :
25kV/µs
Data Rate :
500kbps
Voltage - Supply :
3.3V, 5V
Operating Temperature :
-40°C ~ 85°C
Package / Case :
20-SOIC (0.295", 7.50mm Width)
Description

ADM2587EBRWZ-REEL7 RS422, RS485 Digital Isolator 2500Vrms 2 Channel 500kbps 25kV/µs CMTI 20-SOIC (0.295", 7.50mm Width)

Description:

The ADM2582E/ADM2587E are fully integrated signal and power isolated data transceivers

with ±15 kV ESD protection and are suitable for high speed communication on multipoint transmission

lines. The ADM2582E/ADM2587E include an integrated isolated dc-to-dc power supply, which eliminates

the need for an external dc-to-dc isolation block.

Quick Detail:

Manufacturer
Analog Devices Inc.
Manufacturer Product Number
ADM2587EBRWZ-REEL7
Description
DGT ISO 2.5KV RS422/RS485 20SOIC
Detailed Description
RS422, RS485 Digital Isolator 2500Vrms 2 Channel 500kbps 25kV/µs CMTI 20-SOIC (0.295", 7.50mm Width)

Product Attributes:

TYPE
DESCRIPTION
Category
Digital Isolators
Mfr
Analog Devices Inc.
Series
IsoPower®, iCoupler®
Product Status
Active
Technology
Magnetic Coupling
Type
RS422, RS485
Isolated Power
Yes
Number of Channels
2
Inputs - Side 1/Side 2
44927
Channel Type
Unidirectional
Voltage - Isolation
2500Vrms
Common Mode Transient Immunity (Min)
25kV/µs
Data Rate
500kbps
Rise / Fall Time (Typ)
1.1µs, 1.1µs (Max)
Voltage - Supply
3.3V, 5V
Operating Temperature
-40°C ~ 85°C
Mounting Type
Surface Mount
Package / Case
20-SOIC (0.295", 7.50mm Width)
Supplier Device Package
20-SOIC
Base Product Number
ADM2587

Additional Resources:

ATTRIBUTE DESCRIPTION
Other Names
ADM2587EBRWZ-REEL7TR-ND
ADM2587EBRWZ-REEL7-ND
ADM2587EBRWZREEL7
ADM2587EBRWZ-REEL7CT
ADM2587EBRWZ-REEL7DKR
ADM2587EBRWZ-REEL7DKR-ND
505-ADM2587EBRWZ-REEL7DKR
ADM2587EBRWZ-REEL7CT-ND
-2735-ADM2587EBRWZ-REEL7CT
505-ADM2587EBRWZ-REEL7CT
-2735-ADM2587EBRWZ-REEL7DKR
505-ADM2587EBRWZ-REEL7TR
ADM2587EBRWZ-REEL7TR
Standard Package 400

Data Picture:https://www.analog.com/media/en/technical-documentation/data-sheets/ADM2582E_2587E.pdf

ADM2587EBRWZ-REEL7 RS422 RS485 Digital Isolator Ic 2500Vrms 2 Channel 500kbps 25kV µS CMTI 20-SOIC 0.295
