Mini/Micro LED AOI Equipment for Appearance Inspection
Mini/Micro LED AOI Equipment for Appearance Inspection
Specifications
Brand Name :
MENTO
Model Number :
M2012EL
Certification :
FCC.ROHS,CCC
Place of Origin :
DONGGUAN
MOQ :
3
Payment Terms :
L/C, T/T
Supply Ability :
10pcs+20 work days
Delivery Time :
20 work days
Packaging Details :
1200mm*1500mm*1800mm
Inspection Speed :
Up to 1000mm/s
Product Type :
Automatic Optical Inspection Equipment
Power Supply :
AC 100-240V, 50/60Hz
Led Type :
Mini/Micro LED
Inspection Method :
Automatic
Resolution :
Up to 5μm
Operating System :
Windows
Defect Classification :
Automated classification and sorting
Optical System :
High-resolution camera
Connectivity :
Ethernet, USB
Data Management :
Real-time data analysis and storage
Software :
Advanced image processing software
Field Of View :
Up to 300mm x 300mm
Lighting System :
LED lighting
Defect Detection :
Pixel defects, color defects, surface defects
Description

Mini/Micro LED AOI Equipment for Appearance Inspection

Mini/Micro LED AOI Equipment for Appearance Inspection

Scientific platform design

High-precision testing probes

1. Consistency guarantee of thousands of contact probes

2. Ensuring Mini LED brightness consistency

3. 100,000-cycle operational lifetime.

4. Extremely small pitch and highly dense component solution capabilities

Overall casting platform

Effectively ensuring the stability of the continuous operation

Powerful software system

Mini/Micro LED AOI Equipment for Appearance Inspection

Inspection items: Bad die, over luminescence, under luminescence, chroma anomaly, etc.

Static test: R, G, B, W ;

Dynamic test: horizontal scan, vertical scan, oblique scan (interlaced scan or progressive scan);

Seamlessly connects with automatic rework equipment to provide it with accurate navigation data.

Mini/Micro LED AOI Equipment for Appearance InspectionStatic test: luminescence of red LED Static test: luminescence of green LED Statictest:luminescence of blue LED

Mini/Micro LED appearance inspection
Model M2012EL
Inspection Inspection items Bad die, over luminescence, under luminescence, chroma anomaly
Inspection method Image processing, machine learning
Optical Camera 12MP
Lens High resolution bi-telecentric lens
Resolution 10μm
Light Source RGB
Computer configuration PC CPU:Inteli7, RAM:DDR4-32G, GPU:GTX1660-6G SSD:250G, HDD:2T
Monitor 22 "LED
Operating System Windows 10 Professional 64-bit/Ubuntu
Performance Maximum allowable component height Upper 20mm, Lower 30mm(Customizable)
PCB thickness 1~5mm
Driver Servo motor + Screw guide
Movement speed Max:600mm/s
PCB fixture height 900+20mm (from floor to fixture surface)
Specification PCB size Max:600mmx500mm(single track, track width adjustable)
Power AC220V/50Hz/2000W
Dimensions W1350xD1000xH1650mm(without alarm light)
Weight ≈1100KG
Air Pressure Requirement ≥0.5Mpa
Environmental requirements Temperature:5~40℃, Relative Humidity:25%~80%(no frost)
Upstream and downstream communication Standard SMEMA interface /communication with rework equipment
