On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference
On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference
Specifications
Brand Name :
Merrytek
Model Number :
MC042S
Certification :
CE & R&TTE
Place of Origin :
China
MOQ :
Stop production, not available.
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
20,000pcs per Month
Delivery Time :
1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Packaging Details :
Packed in bubble bags firstly, and then reinforced with carton for outer packing
Input Voltage :
220-240Vac, 50Hz
Rated load :
200W(inductive)
HF system :
5.8GHz ±75MHz, ISM wave band
Approval :
CE , R&TTE
Operation temperature :
-35℃~70℃
Production name :
IP65 waterpoof micrwave motion sensor
Function :
On-off control
Transmitting frequency :
＜0.5mW(1% of transmitting power for ceiling light)
IP Rating :
IP 65
Detection :
Max(D×H):12m×6m
Description

MC042S Independent Waterproof Installation Microwave Motion Sensor / On-off Control 200w for Flood Light

Description:

As MC042s is used Merrytek new 4th generation microwave detection technology and with high quality microwave motion sensor and programming ,the product shows high anti-interference capability on breeze and light rain

Special design, it is suitable for flood light.

MC042S is an innovative and active motion detector with HF system 5.8GHz. It automatically switches on/off light based on motion and ambient light level. Can control all kinds of lamps, for example, halogen, fluorescent and LED lights. Motion can be detected through plastic, glass and thin non-metal materials.

Feature:

1. Automatic switching based on motion and ambient light level.

2. Compact size makes it suitable to fix within most luminaires.

3. 4-pole press-in terminal (L, N, N,L′),easy assembly

4. Zero-crossing point operation helps protect the sensor against in-rush current..

5. 5.8GHz high frequency microwave(C-Band license-free operation)

6. Detection area, time delay and daylight threshold can be precisely set via DIP switch.

7. Water proof sensor with IP65 rating

8. Strong-anti-intergerence capcacity for raindrop and breeze, suitable for outdoor use.

Product Information :

On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference

Function:

ON-OFF function

Wiring:

On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference

Detection Patter:

On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference

Specifications:

Operating voltage

220-240Vac, 50Hz

Rated load

Inductive :200W

HF system

5.8GHz±75MHz, ISM wave band

Power consumption

≤0.5W(standby), <1W(operation)

Transmitting power

<0.5mW

Detection zone Max.(D x H)

10m x 6m

Motion detection

0.5~3m/s

Detection angle

120°(wall installation) 360°(ceiling installation)

IP rating

IP65

Operation temperature

-35℃~70℃

Hold time

5s / 90s / 3min / 20min

Detection sensitivity

50% / 100%

Daylight sensor

25lux / Disable

Life time

50,000 hours

Guaranty

5 years

On-Off Control Independent Floodlight Motion Sensor 200w Anti - Interference

Applications:

Stairwell, Corridor,Balcony, Pathway, etc
