Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Steel CNC Wire Mesh Welding Machine Easy Operate For Construction Mesh
Specifications
Brand Name :
MLG
Model Number :
WHJ-2500
Certification :
CE ISO9001
Place of Origin :
Hebei China
MOQ :
One set
Payment Terms :
L/C, T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4--5 sets per month
Delivery Time :
30 working days after receiving deposit or L/C.
Packaging Details :
1. The main machine and auxiliary equipments will be with plastic package, spare parts in carton box. 2. The main machine will be fixed in the container by steel wire rope to make it stable.
Mesh size :
50*50--200*200mm(adjustable)
Welding speed :
40 - 60 times per min
Voltage :
380V 440V 415V 220V
Mesh type :
mesh panel
Control system :
PLC
Application :
used in fence mesh / construction mesh
Weight :
3.6T
Dimension :
9000mm*3200mm*1700mm
Description

Best Price CNC Wire Mesh Welding EquipmentFor Fence With CE

Function features: Servo motor pulling mesh panel.

1. This CNC wire mesh welding equipment adopts synchronous control technique. The center-control and welding time are composed of Mitsubishi PLC program system. The input front-panel has two forms, touch screen and keyboard that makes the machine more intelligent and reasonable and it could press at one time, times welding.

2. Welding by electromotor; the hopper adopts the step motor; brake motor wheels; pulling the wire mesh is controlled by the servo motor.

3. 140KVA Transformer with water cooling system.

4. The line wire and the weft wire are pre-straight and pre-cut. The greatest advantage is that you can adjust the distance of weft wire at random on the same one piece wire mesh sheet.

5. Mesh pulling system is controlled by servo-motor that adopts elastic tension and opening positioning mesh, which improves the precision of mesh opening size.

6. Wire feeding way:The line wires and cross wires should be pre-straightened and pre-cut, then be put by manual work

7. Material:Suitable for low carbon iron wire, cold drawn wire,or galvanized (cold galvanized, hot galvanized) processing.

Technical parameter

wire diamter 2.5--6.0mm Line wire form Pre-cut wire
Line wire distance 50--200mm(adjustable) Weft wire form Pre-cut wire
Cross wire distance 25--200mm(adjustable) Rated voltage 380V/440V/220V 50Hz
Width of mesh 2500mm Rated power 140KVAx6
Length of mesh 6000mm Welding speed 45--60 times per min
Welding spots 48PCS Motor power 4.0KW
Weight 3.6T Dimension 9000mmx3200mmx1700mm

Application:

Used in municipal engineering, roads, factories, development zones, garden square and other places of safety protection and adornment beautification, its products are aesthetically pleasing, and strong, good anticorrosion, beautify the urban environment project is the first choice of products.Suitable for high volume standard production, easy installation, good structure and good coordination with environment
