Specifications
Brand Name :
Giant Shuttle
Model Number :
WW-0004
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 rolls
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
400 Rolls/Week
Delivery Time :
7Days after receive the deposit
Packaging Details :
In Carton,Wooden box,Pallet or In Bulk
Product name :
316L Stainless Steel Woven Wire Mesh
Mesh Count :
2-635 mesh
Mesh Material :
As Customer Requested
Sample :
Avaliable
Type :
Stainless steel wire mesh
Third Party Inspection :
SGS or other available inspection
Wire Dia :
0.05-1.8mm, Mesh: 6-350mesh/inch,
Appearance :
Plain or twill
Certificates :
ISO
Thickness :
Customers' Request
Length :
30 m/roll
Craftwork :
woven
Mesh :
10 - 100 Mesh
Shape :
Customers' Request
Mesh Width :
Standard less than 2000mm
Description

Description of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads

Stainless steel woven wire mesh comes in different types, each designed to cater to specific needs and requirements.
Plain weave wire mesh, where the wires are woven in an over-and-under pattern, creating a square opening. This type provides excellent stability and a high level of filtration accuracy, making it ideal for fine particle separation, insect screens, and sieving applications.
Twill weave wire mesh, which is characterized by a diagonal pattern created by the interlacing of wires. Twill weave mesh offers enhanced strength and flexibility, making it suitable for heavy-duty applications such as conveyor belts, hydraulic filters, and architectural applications like facades and interior design.

Dutch weave wire mesh is a specialized type that features a tight weave with smaller wire openings. It is created by using thicker wires in the warp direction and finer wires in the weft direction. This design provides superior filtration capabilities and is commonly used in applications requiring precise filtration, such as oil and gas, pharmaceutical, and chemical industries.

Reverse Dutch weave wire mesh is another variant where the thicker wires are used in the weft direction and finer wires in the warp direction. This configuration results in a high flow rate and excellent mechanical stability, making it suitable for pressure filtration, vacuum filters, and liquid-solid separation.

Material of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads
SUS 201,302,304,304L,310,316,316L,321,etc.
Assortment of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads
Electro galvanized square mesh
Hot-dipped galvanized after weaving
Stainless Steel Square Wire Mesh
Application of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads
Square Wire Mesh is mostly used in as windows screening, safety guards on machinery enclosures. It's also widely used in filtering liquid and gas, sieving grain.
Advantages of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads

pure quality material

standard wire diameter

standard mesh and size

uniform mesh opening

corrosion and rust resistance

anti-high temperture.

good filter performance.

long using life,low cost

Features of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads

Corrosion resistance.,

Anti-acid and alkali,

Anti-high temperature.

Technical Parameters of 316L Stainless Steel Woven Wire Mesh For For High Mechanical Loads

Meshes perLinear inch Wire diameter Width of opening Open area
inch mm inch mm percent
1×1 .157 4.0 .84 21.4 71.0
2×2 .118 2.5 .38 10.2 64.0
3×3 .079 2.0 .25 6.4 58.0
4×4 .063 1.6 .187 4.75 56.0
4×4 .047 1.19 .203 5.16 65.9
5×5 .055 1.4 .14 3.68 52.0
6×6 .047 1.2 .12 3.03 51.0
8×8 0.43 1.1 .08 2.08 42.0
10×10 .039 1.0 .06 1.54 36.0
10×10 .020 .51 .080 2.03 64.0
12×12 .023 .584 .060 1.52 51.8
12×12 .020 .508 .063 1.60 57.2
14×14 .023 .584 .048 1.22 45.2
14×14 .020 .508 .051 1.30 51.0
16×16 .018 .457 .0445 1.13 50.7
18×18 .017 .432 .0386 .98 48.3
20×20 .020 .508 .0300 .76 36.0
20×20 .016 .406 .0340 .86 46.2
24×24 .014 .356 .0277 .70 44.2
30×30 .013 .330 .0203 .52 37.1
30×30 .012 .305 .0213 .54 40.8
30×30 .009 .229 .0243 .62 53.1
35×35 .011 .279 .0176 .45 37.9
40×40 .010 .254 .0150 .38 36.0
50×50 .009 .229 .0110 .28 30.3
50×50 .008 .203 .0120 .31 36.0
60×60 .0075 .191 .0092 .23 30.5
60×60 .007 .178 .0097 .25 33.9
70×70 .0065 .165 .0078 .20 29.8
80×80 .0065 .165 .0060 .15 23.0
80×80 .0055 .140 .0070 .18 31.4
90×90 .005 .127 .0061 .16 30.1
100×100 .0045 .114 .0055 .14 30.3
100×100 .004 .102 .0060 .15 36.0
100×100 .0035 .089 .0065 .17 42.3
110×110 .0040 .1016 .0051 .1295 30.7
120×120 .0037 .0940 .0046 .1168 30.7
150×150 .0026 .0060 .0041 .1041 37.4
160×160 .0025 .0635 .0038 .0965 36.4
180×180 .0023 .0584 .0033 .0838 34.7
200×200 .0021 .0533 .0029 .0737 33.6
250×250 .0016 .0406 .0024 .0610 36.0
270×270 .0016 .0406 .0021 .0533 32.2
300×300 .0015 .0381 .0018 .0457 29.7
325×325 .0014 .0356 .0017 .0432 30.0
400×400 .0010 .0254 .0015 .0370 36.0
500×500 .0010 .0254 .0010 .0254 25.0
635×635 .0008 .0203 .0008 .0203 25.0
