Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
Specifications
Brand Name :
Giant Shuttle
Model Number :
WW-0002
Certification :
ISO9001-2015
Place of Origin :
China
MOQ :
500M2
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000SETS PER WEEK
Delivery Time :
10-15 work days
Packaging Details :
In bulk; In pallets
Name :
Gabion mesh cage for construction / Gabion box for stone wall
Processing Service :
Cutting
Keyword :
Gabion Box
Installation :
Easy to assemble and disassemble
Advantages :
Economical
Cetification :
ISO
Materil :
Q235 hot dipped gal galfan wire
Hight :
1.5m
Mesh :
hexagonal shape
Selvage Wire :
3.0-4.0mm
Cage Size :
1*1*1m,2*1*1m,3*1*1m
Wire Diamater :
3mm~6mm or custom
Net Type :
Greenhouses Plastic Sun Shade Net
Sample :
Free sample to confirm quality
Surface treatment :
Hot Dipped Galvanized,Galvanized+PVC Coated
Product name :
Gabion Basket
Feature :
Corrosion Resistance
Usage :
Flood Control Retaining Wall
Description

Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

The double twisted hexagonal wire mesh is to be fabricated in such a manner as to be non-raveling. This is defined as the ability to resist pulling apart at any of the twists or connections forming the mesh when a single wire strand in a section of mesh is cut or broken.

Double Twisted Hexagonal Mesh Gabions & es are commonly used as slope stabilization on steep hillsides, channel linings, bridge protection, revetment mats, sea walls, soil retention, riverbank erosion control, river training, weirs, as a foundation under gabion baskets and other applications.

Standard Specification of Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

Mesh Opening (MM) Steel Wire Diameter (MM) (PVC Wire)/ Inside diameter/Outer diameter(MM)
60X80 2.0-2.8 2.0/3.0-2.8/3.8
80X100 2.2-3.2 2.2/3.2-3.0/4.0
80X120 2.2-3.2 2.2/3.2-3.0/4.0
100X120 2.4-3.5 2.4/3.4-3.2/4.2
100X150 2.4-3.5 2.4/3.4-3.2/4.2
120X150 2.7-4.0 2.7/3.7-3.5/4.5

Advantages of Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

Flexible and simple structure and can filled with most of the in-situ materials.

High permeability help vegetation grow.

Cost-effective and has a long service life.

High tensile strength and toughness.

Simple installation.

Corrosion and abrasion resistance.

Durable and stable structure.

Applications of Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

Mass gravity retaining structures

Mechanically stabilized earth (MSE) walls

Vegetated slope reinforcement

Slope stabilization

Slope reinforcement

Channel lining and channel relocation

Slope and bank protection

Shore and stream bank protection

Weirs, groins, and jetties

Drop structures

Culvert outlet scour pads and headwalls

Bridge abutments

Erosion control

Cover or lids of woven gabions

Rockfall barriers

Road mesh

river bank

Sloe protection

Erosion control

Channel lining

Retaining wall

Vegetation greening system

Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample

Double Twist Metal Gabion Baskets Wall 1.5m Hight Free Sample
