Black Color SCH 40 Steel Pipe Fittings Carbon Steel Concentric Reducer 3x2 Inch
Black Color SCH 40 Steel Pipe Fittings Carbon Steel Concentric Reducer 3x2 Inch
Specifications
Brand Name :
PengXin
Model Number :
A234 WPB
Certification :
ASME
Place of Origin :
China
MOQ :
10 pieces
Price :
consult
Payment Terms :
T/T
Supply Ability :
100000Tons per year
Delivery Time :
2-10weeks
Packaging Details :
Plywood Cases or Pallets
Material :
Carbon Steel
Standard :
ASME B16.9
Shape :
Reducing,elbow
Color :
Black,Can be customed
Packing :
Pallet/plywood case
Description

ASME B16.9 Carbon Steel Conc Reducer, A234 WPB, 3 Inch X 2 Inch, SCH 40

Reducer, used for connection between two pipes of different diameters. According to different shapes, it can be divided into two types: concentric reducer and eccentric reducer.

Function of concentric reducer:

Concentric reducer is, its connection form is directly to the reducer and steel pipe butt welding, steel hot press molding or forging formed. Classification: pushing, pressing, forging. Corresponding to concentric reducers are eccentric reducers made of carbon steel, alloy steel and stainless steel.

Concentric reducer is generally used to connect, for example, the concentric reducer at the outlet of centrifugal pump is to connect the pipeline with the inlet and outlet of the pump. The inlet is generally larger and smaller, and the outlet is generally smaller.

Concentric reducer mainly has the following features:

1. When the flow rate of fluid in the pipeline changes, such as increase or decrease, when the flow rate requirement changes little, the variable diameter pipe should be used.

2. Enter the inlet of the pump to prevent cavitation.

3. In order to match with the connector of instrument, such as flowmeter and regulating valve, reducer is also used.

Main processing technology
  • Raw materials entering the factory
  • Blank cutting
  • Coiled pipe (only in slotted fittings)
  • Welding (only in seam fittings)
  • heating
  • Compression Molding
  • heat treatment
  • Groove processing
  • surface treatment
  • Finished product inspection
  • Logo protection
  • Warehousing and storage

(Note: there is a pickling and passivation process for stainless steel pipe fittings after groove processing)
Product specifications DN15-DN2000 (The diameter of the large and small ends of the rolled seam buffer can reach 3000mm)
Material range Carbon steel, chromium molybdenum steel, low alloy steel, all kinds of stainless steel
Guarantee of main equipment and tooling

1,5000T Press (mainly used for molding)

2,500T Press (mainly used for molding)

3,315T Press (mainly used for molding)

4,150T Press (mainly used for molding)

5,2 gas heating furnaces

6,1 gas heating furnace

7,1 pipe blanking machine

8,Machining equipment:

  • Lathe: Two C630
  • Lathe:One CW6163C
  • Lathe:One CT61100A
  • Milling machine: One a6232A

9,heat treatment:

  • 1Trolley type fuel oil heat treatment furnace, effective heating area of 8 square meters
  • Trolley type box type resistance furnace RT9-80×1500×60

10,2 sets of sand blasting equipment

11,One set of air compressor and one set of liquid cooling pool

12,One 2.4m plate bending machine

13,14 argon arc welding and manual arc welding machines

14,2 welding rod drying equipment

15,260 sets of die pressing mould for reducer

16,One stainless steel pickling tank

17,One manual mouth grinding machine (for large diameter groove treatment)

18,Two plasma cutting machines

Black Color SCH 40 Steel Pipe Fittings Carbon Steel Concentric Reducer 3x2 Inch
