Specifications
Brand Name :
HEBEI PENGXIN
Model Number :
Longitudinal Welded Pipe, Longitudinal Submerged Arc Welded Pipe
Certification :
ASME API
Place of Origin :
CHINA
MOQ :
10 pieces
Price :
Depending on quantity
Payment Terms :
T/T
Supply Ability :
100000Tons per year
Delivery Time :
2-10weeks
Packaging Details :
Plywood Cases or Pallets
Size :
OD: 406mm ~ 1422 mm;WT: 6.4mm ~ 44.5mm;LENGTH: 5mtr ~ 12mtr
Standard & Grade :
ASTM A53 Grade A/B/C
Ends :
Square Ends/Plain Ends (straight cut, saw cut, torch cut),
Usage :
Used for Fluids Transmission, Structural Support in Industrial Construction
Description

The UOE LSAW STEEL PIPE mill features the most advanced technology and process, achieves high production efficiency, stable product quality and is equipped with complete inspection equipment. UOE mill adopts U & O forming, the formed pipes are welded inside through five internal welding stations with three wires, and welded outside through four external welding stations with three wires. In accordance with different requirements of the customers, the welded pipe can be expanded either by mechanical or hydrostatic expand to improve dimensional accuracy, and eliminate residual stress.

Specifications

Outside Diameter 508mm- 1118mm (20″- 44″)
Wall Thickness: 6.0-25.4mm 1/4″-1″
Quality Standards: API,DNV,ISO,DEP,EN,ASTM,DIN,BS,JIS,GB,CSA
Length: 9-12.3m (30′- 40′)
Grades: API 5L A-X90,GB/T9711 L190-L625

JOCE SLAW STEEL PIPE is large diameter longitudinal submerged arc welded (SAWL) pipe production line in China. The mill adopts progressive bending process, featuring evenly distributed forming stress, high uniformity of dimension, infinite sizes variation&wide poduct range, and high flexibility, etc.

Specifications

Outside Diameter406mm- 1626mm (16″ – 64″ )
Wall Thickness:6.0- 75mm (1/4″ – 3″ )
Quality Standards:API,DNV,ISO,DEP,EN,ASTM,DIN,BS,JIS,GB,CSA
Length:3-12.5m ( 10′- 41′ )
Grades:API 5L A-X100, GB/T9711 L190-L690
