Pulse Dust Collecting System Copper Wire Cable Granulator Plant

This waste mixed wire granulator is the dry type one.So it won't pollute the water any more and small cover area.And it is also easy installation and operation.Besides those above ones,the separation rate of this waste mixed wire granulator can reach to 99.99%.The cable/wire granule making machine can separate the copper and plastic from the waste wire,and especially can separate the PE,PVC from the waste plastics.

Application of Large capacity cable wire granulator:
Used for kinds of auto electrical wire,motorcycle wire. Storage battery bike wire. A television wire, washing machine and Refrigerator wire, Air conditioning and other household appliances wire,Telecommunications wire,Computer wire and so on.

Cable Wire Recycling Machine Specifications:

Copper Wire Granulating Machine Description:
1. Compact structure and reasonable layout, safe and reliable, easy to install.
2. Controlled by PLC. Continuous feed, intelligent operation, automatic alarm make it easy to operate and save your time and energy, to ensure the stable operation of the equipment.
3. The shredding machine adopts the high hardness main shaft, make it has more impact power when crushing materials. It is composed of micro cutting head and cylindrical tool rod, greatly reduces the wearing (blades).
4. The crusher, air separator and the pulse dust collector installed together, so the structure of the machine is easy to move and transport.
5. The second crusher adopts alternate blades leading to high productivity, low noise and stable running.
6. This production line use the air separator and the high voltage electrostatic separator together, to improve the recovery rate up to 99%.
7. Back feeding system will crush the unfinished material again, which guarantee the totally separation of copper and plastic.
8. No dust outlet, the dust separation rate can reach up to 99%.
9. The blade and screen adopts special wear resistance and high toughness alloy material, which improve the service life and reduce the production cost.

scrap copper cable wire granulator Working procedure:
When directly put into the machine,used cable is cut into granules first,during this process,copper and plastic is separated but mixed together,then the granules are sent to vibration device for separation,through wind blow and vibration,the copper and plastic are separated,then pure copper comes out from one side and pure plastic comes out from the other side,we collect the separated pure copper and plastic at last.

FAQ:

Q: How will the copper look like after recycling?
A:After processing by this machine, you will get bright copper granules about 3 to 5 mm long.

Q: What if I want to maintain the wire type with just insulation off?
A:You can choose a wire stripper.

Q:How can I find a proper wire granulator?
A:That depends on what kind of raw material you have. Generally it means, this machine can process thin telephone wire, computer wire, industrial wire, automobile wire, etc. They can be single conductor, twin core or multi-core, two strand or multi-strand, straight or twisted. The minimum diameter a wire granulator can process is 0.2mm, maximum diameter is 40mm.

Q: What if I have very thick wires?
A:You can use our wire strippers or use the two machine together.

Q: Is it complicated to install or operate the machine?
A:Not at all. Before shipping out, main parts are assembled together except for several parts for easy transportation. If raw materials are finalized, machines can also be adjusted to work well. They are PLC controlled. English manual are send out together with the machine.

Q:What if we can’t use the machines smoothly?
A:Tell us your problems or making them into videos. We will provide you solutions as soon as we can.
