304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen
304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen
304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen
304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen
Specifications
Brand Name :
CHANT
Model Number :
QT-C-1020
Certification :
CE ISO9000
Place of Origin :
CHINA
MOQ :
30m2
Price :
Usd4.5-20/m2
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000m2/day
Delivery Time :
5-8 days
Packaging Details :
Wooden Case
Material :
Stainless Steel wire
Weave Technique :
Plain Weave
Diameter :
0.02-2.0mm
Wire Grade :
302 304 316 316L etc
Mesh Size :
0.3 Mesh to 500*3500 Mesh
Nickels :
12%
Surface Treatment :
Black Powder Coated,Gray Powder Coated
Usage :
Hookah Strainer
Description

304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen

Product Description

STAINLESS STEEL WIRE MESH

316 Advantages of stainless steel mesh:
8cr-12ni-2.5mo has excellent corrosion resistance, atmospheric corrosion resistance and high temperature strength due to the addition of Mo, so it can be used in harsh conditions, and it is less likely to be corroded than other chromium-nickel stainless steels in brine, sulfur water or brine. The corrosion resistance is better than that of 304 stainless steel mesh, and it has good corrosion resistance in pulp and paper production. Moreover, 316 stainless steel mesh is more resistant to ocean and aggressive industrial atmosphere than 304 stainless steel mesh.

304 Advantages of Stainless Steel Mesh:
304 stainless steel mesh has excellent corrosion resistance and intergranular corrosion resistance. In the experiment, it is concluded that 304 stainless steel mesh has strong corrosion resistance in nitric acid with concentration ≤65% below boiling temperature. It also has good corrosion resistance to alkali solution and most organic and inorganic acids.
producut name stainless steel wire mesh
use It is widely used in mining, chemical, food,petroleum, medicine, machinery and other industries.
material 304,316,316Lstainless steel
Specification list of Stainless Steel Wire Mesh / Woven Wire Cloth
Meshes Per Linear Inch Diameter of Wire Width of Opening Open
Area, %
Inches mm Inches mm
1 0.135 3.5 0.865 21.97 74.8
1 0.120 3.0 0.880 22.35 77.4
1 0.105 2.5 0.895 22.73 80.1
1 0.080 2.0 0.920 23.36 84.6
3/4" 0.120 3.0 0.630 16.00 70.5
3/4" 0.080 2.0 0.670 17.01 79.8
2 x 2 0.120 3.0 0.380 9.65 57.8
2 x 2 0.105 2.5 0.395 10.03 62.4
2 x 2 0.080 2.0 0.420 10.66 70.6
2 x 2 0.063 1.6 0.437 11.10 76.4
2 x 2 0.047 1.2 0.453 11.50 82.1
3 x 3 0.080 2.0 0.253 6.42 57.6
3 x 3 0.063 1.6 0.270 6.85 65.6
3 x 3 0.047 1.2 0.286 7.26 73.6
4 x 4 0.080 2.0 0.170 4.31 46.2
4 x 4 0.063 1.6 0.187 4.75 56.0
4 x 4 0.047 1.2 0.203 5.15 65.9
5 x 5 0.047 1.2 0.153 3.88 58.5
5 x 5 0.041 1.0 0.159 4.01 63.2
6 x 6 0.063 1.6 0.104 2.64 38.9
6 x 6 0.047 1.2 0.120 3.04 51.8
6 x 6 0.035 0.9 0.132 3.35 62.7
8 x 8 0.063 1.6 0.062 1.57 24.6
8 x 8 0.047 1.2 0.078 1.98 38.9
8 x 8 0.035 0.9 0.090 2.28 51.8
8 x 8 0.032 0.8 0.093 2.36 55.4
8 x 8 0.028 0.7 0.097 2.46 60.2
10 x 10 0.047 1.2 0.053 1.34 28.1
10 x 10 0.035 0.9 0.065 1.65 42.3
10 x 10 0.032 0.8 0.068 1.27 46.2
10 x 10 0.025 0.63 0.075 1.90 56.3
12 x 12 0.041 1.0 0.042 1.06 25.4
12 x 12 0.035 0.9 0.048 1.22 33.2
12 x 12 0.032 0.8 0.051 1.29 37.5
12 x 12 0.028 0.7 0.055 1.39 43.6
12 x 12 0.023 0.58 0.060 1.52 51.8
14 x 14 0.032 0.8 0.039 1.52 29.8
14 x 14 0.025 0.63 0.046 0.99 41.5
14 x 14 0.020 0.5 0.051 1.30 51.0
Please consult us for details about other sizes

304 304L 316 316L 317 321 Stainless Steel Wire Mesh Roll Metal Wire Screen

Uses:

1. It is used for screening and filtering in acid and alkali environment, used as mud net in petroleum industry, chemical fiber industry, screen and electroplating. ...
2 Used in mining, petroleum, chemical industry, food, medicine, machinery manufacturing and other industries. ...
3. It can be used for screening and filtering in acid and alkali environment. It can be used as mud net in petroleum industry, screen in chemical fiber industry and acid washing net in electroplating industry. Our factory can design and manufacture various types of products according to users' needs. ...

Classification of stainless steel wire mesh products:

1. Plain stainless steel mesh:
The most common weaving method is widely used in industrial production and civil life, and its main feature is that the warp and weft diameters have the same density.
2. Stainless steel square mesh
Material: galvanized iron wire, stainless steel wire, copper wire, aluminum wire, etc. Features: Precise structure, uniform mesh, good corrosion resistance, firmness and durability. Widely used in industry and construction, screening sand, filtering liquid and gas. It can also be used for safety protection of mechanical accessories, etc., and it can also be used to make walls and ceilings instead of wooden strips.
3. Stainless steel dutch weave wire mesh
Material: stainless steel wire, low carbon steel wire, nickel wire, copper wire, polyester wire, etc. Weaving: plain weave, twill weave, bamboo weave and contrast weave. Features: Good filtering accuracy and high load strength of contrast net. Uses: It is used in aerospace, petroleum, chemical industry, scientific research and transportation industries, and can also be used to make lunch box nets, coal washing nets, etc.

Product features

1.Good acid resistance, alkali resistance and corrosion resistance;
2.High strength, strong tensile strength, toughness and wear resistance, durable;
3.Resistant to high temperature oxidation, the nominal temperature of 304 stainless steel screen is 800 degrees Celsius, and the nominal temperature of 310S stainless steel screen can reach 1150 degrees Celsius;
4.Processing at room temperature, that is, easy plastic processing, makes the use possibility of stainless steel screen diversified;
5.High smoothness, no surface treatment, convenient and simple maintenance.

Weave type
1.Plain weave/double weave: This standard type of wire weaving produces a square opening, where warp threads alternately pass above and below weft threads at right angles.

2.Twill square: It is usually used in applications that need to handle heavy loads and fine filtration. Twill square woven wire mesh presents a unique parallel diagonal pattern.

3.Twill Dutch: Twill Dutch is famous for its super strength, which is achieved by filling a large number of metal wires in the target area of knitting. This woven wire cloth can also filter particles as small as two microns.

4.Reverse plain Dutch: Compared with plain Dutch or twill Dutch, this kind of wire weaving style is characterized by larger warp and less shut thread.
