1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh
1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh
1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh
1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh
Specifications
Brand Name :
QIANTE
Model Number :
QT-C-1040
Certification :
CE ISO9000 SGS
Place of Origin :
CHINA
MOQ :
10m2
Price :
Price negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000m2/week
Delivery Time :
5-8 days
Packaging Details :
Wooden Case
Product name :
Black Oxide Rope Mesh
Key Words :
wire rope mesh,Black Oxide mesh
Material :
Stainless Steel 304 , 316 , 316L
Wire thickness :
1.2mm-4.0mm
Finished :
Black Oxide
Mesh Size: :
25*25-300*300
Usage :
Liquid Filter, Chemical Industry, Curtain
Mesh Angle :
60 Degree
Description

SUS 304 Grade Black Oxide Wire Rope Mesh Ferruled And Knotted Type

Black Oxide Mesh Specification

Cable Diameter Mesh Opening Size
inch mm inch mm
1/8 3.2 4.75 x 4.75 120 x 120
1/8 3.2 4 x 4 102 x 102
1/8 3.2 3.55 x 3.55 90 x 90
1/8 3.2 3 x 3 76 x 76
1/8 3.2 2 x 2 51 x 51
3/32 2.4 4 x 4 102 x 102
3/32 2.4 3.55 x 3.55 90 x 90
3/32 2.4 3 x 3 76 x 76
3/32 2.4 2.4 x 2.4 60 x 60
3/32 2.4 2 x 2 51 x 51
5/64 2 3 x 3 76 x 76
5/64 2 2.4 x 2.4 60 x 60
5/64 2 2 x 2 51 x 51
5/64 2 1-1/2 x 1-1/2 38 x 38
1/16 1.6 3 x 3 76 x 76
1/16 1.6 2 x 2 51 x 51
1/16 1.6 1-1/2 x 1-1/2 38 x 38
1/16 1.6 1.2 x 1.2 30 x 30
1/16 1.6 1 x 1 25.4 x 25.4
3/64 1.2 1-1/2 x 1-1/2 38 x 38
3/64 1.2 1.2 x 1.2 30 x 30
3/64 1.2 1 x 1 25.4 x 25.4
3/64 1.2 4/5 X 4/5 20 x 20

1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh

Black Oxide Wire Rope Mesh Details

Mesh Type Ferruled or Knotted
Mesh Angle 60 degree in rhombus shape
Mesh Orientation Horizontal or Vertical
Panle Measurement Custom-made in width and lenght
Finished Black Oxide
Application Balustrade , Facade Cladding , Animal Enclosure , Aviary Netting

Black Oxide Wire Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316 / AISI316L ; Black Oxide Wire Rope Mesh is custom manufactured to suit your balustrade, railing or architecture application ; Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design ; Diagonal and irregular shapes can also be supplied.

Stainless steel mesh is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of X-TEND – the mesh can even stand up to heavy loads.

Installation

1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh

Our certification

1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh

1.2mm-4.0mm X Tend Cable Mesh Stainless Steel Black Oxide Wire Rope Mesh
