Ocean Cable Protector Ductile Cast Iron With Smooth Surface Iso 9001 Certificate
Ocean Cable Protector Ductile Cast Iron With Smooth Surface Iso 9001 Certificate
Specifications
Brand Name :
JH
Certification :
ISO 9001: 2015
Place of Origin :
CHINA
MOQ :
1pc
Payment Terms :
T/T
Supply Ability :
500 tons/month
Delivery Time :
35 work days
Packaging Details :
wood pallet or wood box
Process :
Resin sand process
Material :
Ductile iron 450-10 grade
Size :
Customized
Casting tolerance :
CT10 for ductile iron sand casting
Machining :
Included
Inspection :
UT/PT
Description

Ocean Cable Protector Ductile Cast Iron With Smooth Surface Iso 9001 Certificate

We are professional comapny supplying ductile iron casting for our customers. We can supplying most of ductile iron castings, following list are the materials which we usually supplying.

Material Rm/MPa(min) Rp0.2/MPa(min) A/%
(min)		 GPa
(min)		 HBW
QT350-22L 350 220 22 169 ≤160
QT350-22R 350 220 22 169 ≤160
QT350-22 350 220 22 169 ≤160
QT400-18L 400 240 18 169 120~175
QT400-18R 400 250 18 169 120~175
QT400-18 400 250 18 169 120~175
QT400-15 400 250 15 169 120~180
QT450-10 450 310 10 169 160~210
QT500-10 500 360 10 169 170~230
QT500-7 500 320 7 169 170~230
QT550-5 550 350 5 172 180~250
QT600-3 600 370 3 174 190~270
QT700-2 700 420 2 176 225~305
QT800-2 800 480 2 176 245~335
QT900-2 900 600 2 280~360


Mechanical properties and main matrix structure of ductile iron castings attached samples:

Material Casting thickness
(mm)		 Ra/MPa
(min)		 Rp0.2 /MPa
(min)		 A%
(min)		 GPa
(min)		 HBW
> ≤
QT350-22A 30 350 220 22 169 ≤160
30 60 330 210 18
60 200 320 200 15
QT400-15A 30 400 250 15 169 135~175
30 60 390 250 14
60 200 370 240 11
QT400-18A 30 400 250 18 169 135~175
30 60 390 250 15
60 200 370 240 12
QT450-10A 30 450 310 10 169 170~210
30 60 420 280 9
60 200 390 260 8
QT500-7 30 500 320 7 169 180~220
30 60 450 300 7
60 200 420 290 5
QT500-10A 30 500 360 10 169 180~220
30 60 490 360
60 200 470 350
QT550-5A 30 550 350 5 172 190~240
30 60 520 330 4
60 200 500 320 3
QT600-3A 30 600 360 3 174 200~250
30 60 600 360 2
60 200 550 340 1
QT700-2A 30 700 420 2 176 250~300
30 60 700 400 2
60 200 650 380 1
QT800-2A 30 800 480 2 176 260~320
30 60
60 200

Ocean Cable Protector Ductile Cast Iron With Smooth Surface Iso 9001 Certificate
