Pvc coated gabions rock mattresses / welded or woven gabion systems

Product Description:

Gabions and rock mattresses

Gabions and rock mattresses are baskets or cages manufactured from heavily galvanized wire or pvc coated wire.

Applications include:

Retaining walls
Weirs and drop structures
Culvert protection
Bridge abutment protection
Channel lining
Landscaping
Rockfall protection netting (mesh)
Erosion control and stabilization.

Gabions are box like units, generally of length either 2m or 4m and with a height of either 0.5m or 1m. Rock Mattress product is generally of larger plan area, typically 6m x 2m, but are much thinner in depth with typical dimensions ranging between 0.17m and 0.5m. All units are supplied folded flat to site and the customer must fabricate the supplied unit to size, join one unit to another to form the required structure, fill with suitable stone, and the material is heavy zinc coated wire, we promise we will give you our best quality and service.

Sizes of River mattress/:

How to built gabions?

Step 1
Open the bundle and unfold each unit.

Step 2
Lift the sides, the ends and the diaphragms of each unit into vertical position.

Step 3
Attach the sides of four corners together with locking wire fastener or lacing wire and the diaphragms to the front and back of the gabion.

Surface treatment of gabion mattress: The woven steel wire used to manufacture the mattress is heavy zinc coated steel wire or pvc coated wire.

Advantages of Gabion Mattress:

Gabion mattress strength lies in the double twisted hexagonal steel wire mesh or welded mesh panels.
The base section is divided into compartments to restrict the movement of stone and strengthen the structure
The lid is supplied as a separate panel
The wire will not unravel even when cut
Easily assembled
Free drainage and 30-35% voids allow vegetation to grow

When requesting a quote, please specify:

size of units (LxWxH)
type of mesh size (60*80,80*100mm)
type of coating (galvanized wire, galfan wire,pvc coated wire)
Wire diameter(2mm,3mm)
