Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
Specifications
Brand Name :
BaoSteel
Model Number :
Copolymer Coated Copper Tape
Certification :
ANSI JIS AISI AWS
Place of Origin :
China
MOQ :
1 ton
Price :
123
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
333tons/week
Delivery Time :
5-25days
Packaging Details :
Wooden pallets and container
Name :
Cu 0.2mmCopolymer Coated Copper Tape
Color :
Natural
Tensile strength :
MPa ≥180 ASTM B152
Peel strength :
N/cm ≥5 ASTM B694
Corrosion resistance(0.1 mol/L,Hcl,480h) :
Grade ≥7
conductivity :
IACS ≥90%
Dielectric Strength(one side DC 1kv1min two sides DC 2kV.1min) :
No Break
Description

Cu 0.2mm Natural Copolymer Coated Copper Tape EAA 0.05 mm

Copolymer coated copper tape applies for medium and high voltage power cables as a layer of shield/moisture barrier for cable core,Copper plastic composite has two functions: one is metal shielding, and the other is water blocking and moisture-proof.The thickness of the copper foil in the copper plastic composite belt is smaller than that of the copper strip, so a plastic layer is needed to increase the strength, facilitate processing, and reduce the cost.the plastic layer melts and swells under the condition of heat, and the condensation resistance gap can play a waterproof role.

Color Natural
Thickness(Cu)

0.2mm
Thickness(EAA) 0.05mm
Tensile Strength MPa ≥180 ASTM B152
Peel strength N/cm ≥5 ASTM B694
Heat Seal strength N/cm ≥17.5 ASTM B694
Dielectric Strength(one side DC 1kv,1min two sides DC 2kV1min No Break

Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm

Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm

Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm

Cu 0.2mm Copolymer Coated Copper Tape Natural EAA 0.05 Mm
