Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
Specifications
Brand Name :
BaoSteel
Model Number :
Copolymer Coated Copper Tape
Certification :
ANSI JIS AISI AWS
Place of Origin :
China
MOQ :
1 ton
Price :
123
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
333tons/week
Delivery Time :
5-25days
Packaging Details :
Wooden pallets and container
Name :
Cu 0.1-0.3mmCopolymer Coated Copper Tape
Color :
Natural
Tensile strength :
MPa ≥180 ASTM B152
Elongation at break :
% ≥20 ASTM B152
Peel strength :
N/cm ≥5 ASTM B694
Heat Seal strength :
N/cm ≥17.5 ASTM B694
Corrosion resistance(0.1 mol/L,Hcl,480h) :
Grade ≥7
conductivity :
IACS ≥90%
Dielectric Strength(one side DC 1kv1min two sides DC 2kV.1min) :
No Break
Description

Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm

Copolymer coated copper tape applies for medium and high voltage power cables as a layer of shield/moisture barrier for cable core,it consists of copper tape coated with single side copolymer.The coating forms a strong moisture-resistant bond to copper substrate, also form strong polymeric bonds to zero halogen,polyethylene and chlorinated polyethylene jacketing resins during jacket extrusion process.

Color Natural
Thickness(Cu)

0.1-0.3 mm
Thickness(EAA) 0.05mm
Tensile Strength MPa ≥180 ASTM B152
Peel strength N/cm ≥5 ASTM B694
Heat Seal strength N/cm ≥17.5 ASTM B694
Dielectric Strength(one side DC 1kv,1min two sides DC 2kV1min No Break

Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm

Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm

Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm

Cu 0.1-0.3mm Natural Copolymer Coated Copper Tape EAA 0.05 mm
