Label Laser Spot Welding Machine Solar Modules With CCD Camera Cooling Type

Description:

1. Britain imported ceramic cavity.

2. Composite rotatable lifting platform.

3. strong technical team and professional sales 4.No special foundations required,low operating cost,easy to operaiton.

5. Low noise and no pollution.

6. Provide the best sincere service to our customers ,we always online 24/7 hours.

7. Low cost, dose not require any welding material.

8. Low consumables, free of maintenance.

9. No black no deformation after welding.

Breif introduction to the machine

The laser welding machine for mould working principle is based on themal energy and focus on spot welding technology. It can effectively deal with all small partts welding and repairing work,which perfect the traditional welding technology in this field . And this technology avoids the thermal strain and post-processing the two threshold, shorten the mould production cycle.

Application for the machine

Widely used in aviation,aerospace,sporting goods,jewelry,golf

head,medical,equipment,aluminum,alloy denture,instrumentation,electronic,

mechanical processing,automobile and other industries,especislly for gold and

silver jewelry fill holes,spot weld lines,Mosaic forces and claw foot position welding

Model Features

The laser repairing mold has the following advantages compared with other welding methods such as
argon arc welding :
·Laser welding point diameter is only 0.2mm~2.0mm;
·Use 1064nm wavelength laser, harmless to human body;
·Small heating range, no deformation, won't appear the blow hole; processable material such as, die
steel, stainless steel, beryllium copper and heavy meta,etc.
·Can repair cracks, collapse angle, die side, and the wear of the sealing edge;
·After welding, it can be processed into light surface;
·Can be welded in the extremely hard materials (~HRC 60).

Techinical Parameters

Jewelry Laser welding Machine

Model: LX-D11

Max.Output: 200W

Wavelength: 1064nm

Laser Type: Nd: YAG

Welding Depth: ≤1.2mm

Pulse Frequency: 0-50Hz

Laser Spot Size: 0.2-3mm

Checking System: Microscope

Protective Gas: Argon

Output Focal Length: 80mmm---200mm

Holistic Power: 6KW

Power Supply: 380V/50HZ
