30W 60W CO2 Laser Marking Machine High Speed Air Cooling For Ceramic Engraving
30W 60W CO2 Laser Marking Machine High Speed Air Cooling For Ceramic Engraving
Specifications
Brand Name :
LINXUAN
Model Number :
LX-B2
Certification :
CE, FDA
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
5-8 work days
Packaging Details :
wooden case
Application :
Laser engraving
Engraving area :
110mm*110mm
Control Software :
Ezcad or Marking mate
CNC or NOT :
YES
Laser power :
30W
Cooling model :
Air Cooling
Description

New Model 30W 60W Co2 Laser Marking Machine for Ceramic engraving

Description

CO2 laser marking machine integrates advanced Galvanometer laser marking technology with imported RF excited sealed CO2 laser .It's a high-performance laser equipment which let laser beam through expander,galvanometer,focusing, at last by controlling galvanometer deflection to achieve marking.

Product Features

1. Adopt high-speed galvanometer and 16-bit PCI cards, marking speed is 30% faster than similar products.

2. High repeat positioning accuracy.

3. Stable performance , high security.

4. Customer friendly operation interface and easy to operate.

5. Integrated structure, compact volume.

Application

Suitable for almost all non-metal materials, including leather, rubber, wood board, bamboo products, organic glass, ceramic tile, plastics, marble, jade, crystal, cloth, etc.

Widely used in industries of arts & crafts, bamboo and wood products, advertising decoration, clothing, plate making for printing on leather, decoration and architectural model.

Specifications

Machine Type co2 laser marking machine
Laser Type American SYNRAD or RF laser source
Laser output power 10W 30W 60W
Laser tube life time 30000-40000 hours
Applicable materials Non-Metallic Materials
Standard Working area 110mm*110mm
Optional Working area 70mm*70mm, 140mm*140mm, 175mm*175mm
Marking depth 0.01mm-0.3mm
Maximum marking speed 7000mm/s
Laser wavelength 10.64um
Minimum Line Width 0.015mm
Repetition Accuracy ±0.01mm
Power Supply 220/110V(50HZ/60HZ)
Machine power consumption 300W/1.2KW/2KW


Marking Samples

30W 60W CO2 Laser Marking Machine High Speed Air Cooling For Ceramic Engraving

Packaging and delivery

1. Standard plywood case, its compressive strength and bearing quality is better.
2. the board area is bit, the soil structure is good, it is better in leakproofness and waterproof.
3. when importing, the plywood case is with fumigation-free, the procedure is simple.
4. Delivery Detail: within 5-7 days after received your payment.
