Metal Tube Mini Laser Marking Machine , Air Cooling Plastic Engraving Machine
Metal Tube Mini Laser Marking Machine , Air Cooling Plastic Engraving Machine
Specifications
Brand Name :
LINXUAN
Model Number :
LX-B2
Certification :
CE,FDA certificate
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
5-8 working days
Packaging Details :
wooden case
Laser source :
Metal tube
Laser Wavelength :
10.64um
Machine power :
30w
Cooling System :
Air Cooling
Marking Depth :
<3mm
Description

Mini Portable CO2 Laser Marking Machine for bottle

Description

Adopting fiber laser output the laser ,then using ultra high-speed scanning galvanometer system to marking. The critical component use long lifetime stable device. It has lots of advantages : novel appearance,unique structure,convenient operation,high modulating frequency,fast marking speed,high precision,stable performance .It can widely used in various metal and non-metallic surface to output the permanent mark.

Product Features

1. LINXUAN LASER’s CO2 Laser Marking Machine equips with the most advanced metal SYNRAD CO2 laser source, can be refilled with CO2 gas, no need to change consumables, exempt-maintenance and long life time.
2. With high-rate of photoelectric conversion and SYNRAD metal tube, the laser beam mode is much better than common machine with glass laser tube, and the high accuracy marking effect is what common CO2 laser marker can not achieve.
3. With multifunctional marking software, the machine can be collocated with ital-controlled rotary accessory, automatic fixture, and production line.

Application

This Laser marking machine Widely used in leather, bags, artwork, wooden household items, glasses, plastic packaging, glass, clothing, shoes, hats carved cutting., etc.

Laser,fabric,paper,wood products,acrylic,crystal,ceramic,marble,and a variety of non-metallic

composite materials

Specifications

Machine Type co2 laser marking machine
Laser Type American SYNRAD or RF laser source
Laser output power 10W 30W 60W
Laser tube life time 30000-40000 hours
Applicable materials Non-Metallic Materials
Standard Working area 110mm*110mm
Optional Working area 70mm*70mm, 140mm*140mm, 175mm*175mm
Marking depth 0.01mm-0.3mm
Maximum marking speed 7000mm/s
Laser wavelength 10.64um
Minimum Line Width 0.015mm
Repetition Accuracy ±0.01mm
Power Supply 220/110V(50HZ/60HZ)
Machine power consumption 300W/1.2KW/2KW


Marking Samples

Metal Tube Mini Laser Marking Machine , Air Cooling Plastic Engraving Machine

Packaging and delivery

1. Machine package with wooden case.
2. Delivery can be by air, by sea and by DHL express.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
