Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Intermediate House Rolling Mill Stand , Universal Metal Rolling Mill house
Specifications
Brand Name :
SEEC
Model Number :
Rolling mill
Certification :
ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
As required
Delivery Time :
6-8months
Packaging Details :
Standard international package
Type :
Rolling Mill
material 1 :
Carbon structure
Material 2 :
structure for bridge
Material 3 :
low alloy structure
Material 4 :
structure for mine
Material 5 :
cast steel
Description

Rolling Mill Stand Universal Mill finish house intermediate house

  1. Universal Mill

Sample product:

H beam with large edge:

H125×125×6.5×9, H150×150×7×10, H175×175×7.5×11,

H beam with Medium edge:

H200×204×12×12, H148×100×12×12, H194×150×6×9, H244×175×7×11, H294×200×8×12,

H beam with nerrow edge:H198×99×4.5×7, H200×100×5.5×8, H248×124×5×8, H250×125×6×9,

H298×149×5.5×8, H300×150×6.6×9, H346×174×6×9, H350×175×7×11, H400×200×8×13

Steel grade: Carbon structure, structure for bridge, structure for mine, low alloy structure

Raw material size:

280×280 mm x 6m

280×380 mm x 6m

220×220mm x 7m

320×410mm x10m

Features and applications
1,Suitable for mild steel,stainless steel,and special steel,especially for high precision wider and thin coils.
2,That hydraulic bending devices and middle rolles horizontal moving installations can fast regulate the roller's gibbous degree to change the distribution of touching pressure between rollers in order to eliminate the harmful touching areas of rollers to aim to control the plate shape and gibbous degree.
3,Flat,stability,and controllable.It's effective to improve thinner of strip edges and cracks with smaller working rollers to enhance pressure force and total pressure force of rolling routes.Type of working rollers is flat rollers which reduce the requirements of spare parts and consumption.
4,It is equipped with AGC system to get high precision,which is especially suitable for rolling high precision requirempents of wider coils and thinner coils.
Components
Pay-off reel(loading car)→head straightening unit→entry tension reel(unloading car)→Front devices→six roller master mill→Rear device→exit tension reel(unloading car) →(auxiliary coiler)

Technical parameters
φ150
φ175
φ460×450
φ150
φ175
φ500×500
φ165
φ200
φ630×650
φ165
φ250
φ680×800
φ170
φ300
φ800×900
φ300
φ370
φ950×1050
φ330
φ370
φ1050×1250
φ400
φ450
φ1250×1450
Input thickness
1.0-2.5
1.0-2.5
1.0-3.5
1.0-3.5
2.0-4.0
2.0-4.0
2.0-4.0
2.0-4.0
Product thickness
0.15-1.2
0.15-5
0.18-2.0
0.2-2.0
0.2-2.0
0.2-2.0
0.2-2.0
0.2-2.0
Strip width
250-350
300-400
400-550
550-700
700-900
650-950
700-1100
900-1250
Transmission
Working
roll
Working
roll
Working
roll
Working
roll
Working
roll
Working
roll
Working
roll
Working
roll
Rolling force
2800
3500
5000
5500
6500
10000
12000
15000
Pressdown method
elect-ric
hydra-ulic
elect-ric
hydr-aulic
elect-ric
hydr-aulic
elect-ric
hydr-aulic
elect-ric
hydr-aulic
hydr-aulic
hydr-aulic
hydr-aulic
Speed(m/s)
3.5
4-6.5
3.5
4-8
3.5
4-5
3.5
4-5
3.5
4-5
10
8-12
8-16
Rollling material
common steel
common steel
stainless steel ,common steel
stainless steel
stainless ste
