Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
Specifications
Brand Name :
SEEC
Model Number :
Rolling mill
Certification :
ISO
Place of Origin :
China
Supply Ability :
As required
Delivery Time :
3-6months
Packaging Details :
Standard international package
MOQ :
10
type :
hot rolling mill and cold rolling mill
material :
forged steel
application :
Horizontal roll shaft for universal mill
standard :
ISO9001
drawing :
as confirmed
hardness :
as per drawing
Description

Forged Steel Rolls for Horizontal roll shaft for universal mill

  • Our company could supply all kinds of forging steel work roll ,back up roll, intermediate roll and other rolls .

  • Application :
  • Hot rolled steel strip rolling mill
  • Cold rolled steel strip rolling mil
  • Section steel booming
  • Section steel roughing rolling
  • Universal section mill

  • Roll size range

Forged steel cold rolled work roll :,max weight :20 Tons

Forged steel hot rolled work roll : , max weight :20 Tons

Forged steel back up roll : max weight :20 Tons

  • Roll steel grade :

including 60CrMo, 9Cr2Mo , 86CrMoV7 , 70Cr3Mo etc .

Roller classification

(HS)

Hardness (HS)

 Neck strength (MPA) Main Application

2%-8%Cr

2%-8%Cr forged steel cold mill roll

 90-102 ≥900 Cold strip mill work roller
75-85 ≥900 Intermediate roll for cold strip mill
Fared HSS(high speed steel)roll 88-95 ≥900 Cold strip mill work roller

50-60CrMnMo Cr2-Cr5

50-60CrMnMo forged steel roll; Cr2-Cr5 forged steel roller

 55-80 ≥850 Backup rollers for cold and hot strip mills
Forged steel hot mill roller 35-50 ≥800 Blooming or roughing roller for section mill
Horizontal roll shaft for universal mill 35-50 ≥800 Horizontal roller shaft for universal section mill

Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill

Horizontal Forged Steel Tool Roll Cast Iron Rolls For Universal Strip Steel Mill
