Usb Interface Embedded Numeric Keypad Ip65 Waterproof Grade Metal Material
Usb Interface Embedded Numeric Keypad Ip65 Waterproof Grade Metal Material
Usb Interface Embedded Numeric Keypad Ip65 Waterproof Grade Metal Material
Usb Interface Embedded Numeric Keypad Ip65 Waterproof Grade Metal Material
Specifications
Brand Name :
guangzhi
Model Number :
GZ-C001013
Certification :
FDA, SGS, ROHS, LFGB, REACH
Place of Origin :
SHENZHEN CHINA
MOQ :
1PCS
Price :
To be quoted
Payment Terms :
T/T
Supply Ability :
10000pcs
Delivery Time :
1-20 work days
Packaging Details :
Individual product package size:235*150*50mm, Carton Size:482*320*275;
Warranty :
1year
Connection :
USB or PS2
Material :
Stainless steel 304
keys :
68
Name :
wireless numeric keypad
Description

IP 65 industrial controller membrane USB interface metal keyboard;

Product name:Embedded Numeric Keypad

Model: GZ-C001013

front panel Size:299*110mm

PARAMETERS 　
Defend Grade IP65
Keys 68 keys
Vandal resistant IK09
Electrical lifetime > 5 years
Contact resistance 200 ohm (max)
Current Rating appr. 30mA
Power supply + 5V +/- 5%
Led color option
G.W. 1kg approx
Frame/keys materials Stainless steel
life span ≥2 million
Elasticity of key 2.5-3N
Key travel ≤100Ω
Atmospheric pressure 60-106Kpa
Operate Temperature -40℃~+85℃
Travel distance 0.45mm

Product Description: stainless steel keyboard, number keys, twenty-eight function keys and twenty-six letters, compact layout of keys, using 0.5mm long key stroke, installation method from inside to outside, the whole thickness is: 33mm, using all stainless steel panel and laser engraved key design, mold with precision and accuracy, beautiful surface treatment. Key value can be customized;

Material

Face plate: 304 stainless steel

Keys: 304 stainless steel

Back plate: SUS304

Special feature:

Full travel keys, excellent typing feel;

Specially designed to operate in harsh environments, making them ideal for kiosks and other applications in public places.

Built from stainless steel,resistant to vandalism,corrosive,rust

Dust-proof and liquid-proof, IP65 compliant

Physical properties

Keys stainless steel keypad, Dot matrix keypad

Carbon-on-gold key switch technology

Rear mounting/bracket mounting

USB or PS2 interface available

Custom layout available,generally English layout

Keys :

keyboard keys can be defined according to customer requirements

Key life: more than 200 million times

Key travel: 0.2mm

Key strength: 3N

Operating temperature: -40 ℃ -65 ℃

Keycaps:

keycap font is black, the function keys have colored icon

etched keycaps graphic, paint by special process

keycap graphic can be customized

Operating system

Operating system: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Windows 7, Windows 8, Windows 9, Windows 10, Linux, Unix, Mac osx

Electrical Data

Power supply voltage: DC 5 V ± 5%

Current rating: 20 mA

Interface: USB or PS2

EMC Emission:EN55022(B)

Environmental adaptability

Operating temprature:-25℃~+70℃

relative humidity:30%~90%RH

Storage temprature:-25℃~+70℃

relative humitity:20%~95%RH(non-condensate)

BARO:60~106Kpa
