Matrix Metal Numeric Keypad 16 Keys Type For Access Control Kiosk Elevator Atm
Matrix Metal Numeric Keypad 16 Keys Type For Access Control Kiosk Elevator Atm
Specifications
Brand Name :
guangzhi
Model Number :
GZ-B005013
Certification :
CE、FCC、RoHS
Place of Origin :
SZENZHEN CHINA
MOQ :
1pcs
Price :
To be quoted
Payment Terms :
T/T
Supply Ability :
1000000pcs
Delivery Time :
1-20 work days
Packaging Details :
Individual product package size:235*150*50mm, Carton Size:482*320*275;
Keypad button material :
Metal, Silicone, Rubber, PET, Stainless steel
Size :
87.5*91.5MM
Warranty :
1 Year
Material :
Silicone stainless steel
Type :
Meet Customer's Demand, Manufactuer, rugged numeric keypad, Usb keypad, Waterproof Membrane
Printing :
Digital Printing OR laser Marking
Description

16 Keys Matrix Numeric Metal Keyboard For Access Control Kiosk Elevator ATM

Product Name: Metal Numeric Keypad

Product P/N:GZ-B005013

Product Size:87.5*91.5mm

Product Application:

Mainly used in various unsupervised or semi-regulated information terminals, such as Internet terminals, universities, shopping malls, hotels, banks, airports, stations and other public information kiosks, ticket vending machines, gas stations, bank tellers ( Automatic deposit/detail machine), public telephone, etc.

Mechanical Specifications:

1. Button: digital button and six function keys, imported printed brushed SUS304 stainless steel.

2. Button font: can be laser engraved, can be used to fill out the pattern and characters

3. The size of the button: 13.8mm * 13.8mm, 13.8 * 27.8mm

4. Button stroke: 0.5mm

5. Button life: Operate more than 2 million times / per button, the pot is made of imported gold plated material.

6. Button strength: 1.2N +/- 0.1N (contact force)

7. Front panel: imported printed brushed SUS304 stainless steel, 1.5mm thick

Electric parameter:

1. Operating current: Direct current+5V/-5%

2 working current:20mA

3 Expected life-time:>2yer

4. Button switch technology: Matel Dome key

5. Interface Technology:USB,PS2,R232,8PIN

6. Operating System:DOS/Windows95/98/NT/ME/2000/2003/XP/Vista, Linux, Unix, Mac osx

interface

USB

woriking current

≈20mA

PS /2

explosion-proof degree

IK07

ribbon cable 8 pins

waterproof rate

IP65

cable length

USB: 2m

ESD protection

above 6kV

PS/2: 2M

MTBF

>20000h

ribbon cable 8 pins: 15cm

MTTR

<30min

operating voltage

+5.0V DC±5%

operation system

win 98,2000,XP,VISTA,win 7,win 8,win10,Linux

Environmental adaptation:

1. Operating Temperature:-20℃to+60℃

2. Storage Temperature:-30℃to+70℃

3. Relative Humidity: 30-90% without Condensation dew

4. Atmospheric Pressure:50-100Kpa
Matrix Metal Numeric Keypad 16 Keys Type For Access Control Kiosk Elevator Atm
